WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine

WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-1
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-2
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-3
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-4
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-5
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-6
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine thumbnail-7
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-1
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-2
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-3
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-4
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-5
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-6
WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine photo-7
US$ 1,100 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
WDS-02/03/1/2/3/5
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HST
Place of Origin Shandong, China
Model Number WDS-02/03/1/2/3/5
Power Electronic

WDS CE Digital Manual Tensile Test Machine

WDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test MachineWDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test MachineWDS -1 2 3 5kn CE Digital Electronic Universal Manual Tensile Test Machine



Product Description



1. Application:

WDSPE Tensile Testing equipment are designed and manufactured according to

ASTM, ISO, DIN, GB and other international standards. Applicable for wide range of material for tensile, compression, bending, shearing and low cycle test. It is for metal, rubber, plastic, spring, textile, and components testing. Widely used in the corresponding industries, research and development, test institutes and training centers etc.



2. Features:

1. Automatic calibration: system can automatically realize the accuracy of the calibration value

2. Automatic stop: After the sample broken, automatic stop.

3. Automatic display: Real-time display testing force, displacement, testing speed, peak value, testing status on one LCD.

4. Automatic return: beam automatic return to initial position when testing finished.

5. Breakage judgment: sample after fracture,beam automatic stop moving

6. Limiting protection: Program control and Mechanical limiting protection.

7.Overload protection: When more than 3 ~ 5% of the rated load device automatically stop working

8. Automatic calculation: automatic calculation area after input sample diameter (round); Width, thickness (flat), sample gauge . ect



3. Technical parameter:

Model

WDS-

005

WDS

-01

WDS-

02

WDS-

05

WDS-

1

WDS-

2

WDS-

3

WDS-

5

Max load

50

100

200

500

1000

2000

3000

5000

Structure

Single column double spaces

Control mode

single chip control

Test accuracy

1 class ( or 0.5class)

Test force test range(F·S)

2%~100%F·S (or 0.4%-100%F.S )

Test force value relative error (%)

≤±1% (or ≤±0.5% )

Disp. Value relative error(%)

≤±1%

Disp. Resolution (mm)

0.01mm

Speed adjusting range

0.05-500mm/min(stepless speed adjusting)

Disp. Value relative error(%)

Standard: 600mm, heighten: 850mm(can customize)

Disp. Resolution (mm)

Standard 600mm, heighten: 850mm(can customize)

Main unit power

AC220V±10%,50Hz

Dimension

550×400×1600mm

Weight

About 100kg
