Rexroth proportional valve 4WRKE 25 E350L-33-6EG24EK31-A1D3M

Name: Rexroth proportional valve 4WRKE 25 E350L-33-6EG24EK31-A1D3M
Brand: Rexroth
Price: USD $18,000 - 28,000 / Set

FOB Price

USD $18,000 - $28,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port Any port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

Rexroth

Place of Origin:

Germany

Pressure:

High Pressure

Product Description

The pilot control valve is a direct-acting proportional valve. The geometry of the control edge is optimized for use as a pilot control valve for proportional directional valve model 4WRKE. Proportional electromagnets are pressure-resistant, sealed, wet-type, direct-current coils with removable coils. They convert electrical current into mechanical force proportionally. An increase in current causes a corresponding increase in the magnetic force of the coil. The set coil magnetic force will remain constant throughout the control stroke. product features --- Pilot-operated two-stage proportional directional valve with electrical position feedback of the main control spool and integrated electronics (OBE)；

--- Adjust the direction and size of volume flow；

--- Operate with proportional electromagnet；

--- For bottom plate installation: hole diagram according to ISO 4401；

--- Electrical position feedback；

--- Spring-centered main control spool；

--- Pilot control valve: single-stage proportional directional valve；

--- Main stage with position control；

Technical Parameters

specification			10	16	25	27	32	35
Working pressure			350
Working pressure	Interface P	315	350			210	350
		Anschluss A	315	350			210	350
		Port B	315	350			210	350
Working pressure range			25---315
Maximum return pressure	Port T, external pilot oil return	315	250			210	250
		Port T, internal pilot oil return	10
		Port Y	10
Maximum flow			170	460	870	1000	1600	3000
Hydraulic oil temperature range	-20 … +80							-20 … +80
Hydraulic oil temperature range		-40 … +50

Related Products

Packing&Shipping

In order to ensure that the product is not damaged during transportation, we will choose to use high-hardness cardboard boxes or wooden boxes to package the product according to the volume of the product, and adopt protective measures such as foam anti-collision and wooden frame fixing to ensure the safe and non-destructive delivery of the goods to the greatest extent. Reach customers.
