Rexroth Proportional Flow Control Valve 2FRE 10-44-50LBK4M
US$ 8,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Rexroth
Place of Origin:
Germany
Model Number:
2FRE 10-44-50LBK4M
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
German Rexroth Proportional Valve 4WRAE 10 W1-60-22 / G24N9K31 / F1V Use for MetallurgyUS$ 8,000 - 15,000MOQ: 1 Set -
Rexroth Proportional Valve 4WRBKE 27 W430SJ Use for Rubber Plastic MachineUS$ 18,000 - 28,000MOQ: 1 Set
-
Rexroth Proportional Valve 4WREE 10 E75-23-G24K31-A1V Rotary ValveUS$ 8,000 - 15,000MOQ: 1 Set
-
Rexroth Hydraulic Proportional Valve 4WRKE 16 E200L-33-6EG24EK31-A1D3MUS$ 8,000 - 15,000MOQ: 1 Set
-
Rexroth 4WRSE 6 V10 High Precision Proportional Directional Valve for Injection Molding MachinesUS$ 4,000 - 8,000MOQ: 1 Set
Brand Name
Rexroth
Place of Origin
Germany
Model Number
2FRE 10-44-50LBK4M
Pressure
High Pressure
Product Description
The 2FRE type proportional flow control valves have a two-way function, which can control the flow shown in the control value of the appliance through pressure and a large amount of temperature compensation.
product features:
--- Valve with pressure balancing valve for pressure-compensated closed-loop control of liquid flow
---- Controlled by proportional electromagnet
--- For floor mounting: the mounting surface of the oil port complies with ISO 6263
--- Electrical position control with orifice
--- Axial movable position sensor coil, so you can easily achieve the zero calibration of the orifice, without disturbing the control electronics (electro-hydraulic)
--- Low manufacturing tolerances for valves, electrical amplifiers and amplifier modules
--- Adjust the speed in both directions through the flow direction adjustment board
Technical Parameters
Proportional valve model |
2FRE |
2FRE |
|||
specification |
10 |
16 |
|||
Working pressure |
bar |
315 |
|||
Maximum flow |
l/min |
60 |
160 |
||
Linear l/min |
60 |
160 |
|||
Progressive and rapid feed l/min |
40 |
------ |
|||
Minimum pressure difference |
bar |
3 … 8 |
6 … 10 |
||
Temperature drift |
Hydraulic and electrical % |
0.1 |
|||
Pressure compensation % |
± 2 |
||||
Hydraulic oil temperature range |
°C |
-20 … +80 |
|||
Viscosity range |
mm²/s |
15 … 380 |
|||
