Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M

Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M thumbnail-1
Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M thumbnail-2
Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M thumbnail-3
Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M photo-1
Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M photo-2
Rexroth Proportional Valve4WRLE16 E1Z-180SJ-3X /G24 KO/A1M photo-3
US$ 100 - 101 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Bosch Rexroth
Place of Origin:
Germany
Power:
/
Contact Supplier Request Quote Chat Now
Shenzhen Ou Hang Fluid Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Bosch Rexroth
Place of Origin Germany
Pressure High Pressure
Product Description
features: *Pilot controlled servosolenoid valve from port 10 to port 32; *It has 6 pilot valve with control piston and valve sleeve and servo performance; *Four position four-way fault support position on one side during power failure; *Control electromagnetic iron belt integrated feedback and integrated amplifier board (OBE) calibration in the factory; *The main stage with servo performance has position feedback; *Flow characteristics ·M = progressive form with fine details ·P = nonlinear curve ·L = linear (available only when required) *Electrical connection 6p + PE Signal input differential amplifier with interface Al earth 10V or interface F14 20 mA （Rs（200Q) *Suitable for electro-hydraulic controller in production and test system *For the installation of base plate, the installation hole is arranged according to the Diameter 10 is 150 4401-05.05-0-94, Diameter 16 in accordance with 150 4401.07-06-0-94, Diameter 25 in accordance with 150 4401-8.07.0.94, Drift 32 in line! 50 4401.10.08-0-94 *Base plate as sample, bore 10 re 45055, bore 16 RC 45 057, bore 25 RC 45 059 and bore 32 RC 45 060 (ordered separately;) *Wiring plug according to DIN 435 63 - am6. See sample RC 08 008 (ordered separately);
Technical Parameters
Summary
structure
Slide valve type, pilot control
drive
4wreh servo solenoid valve ng6-obe with position controller for pilot valve and main stage
Installation form
Base plate installation, mounting face diameter 10 35（ISO 4401）
Installation position
Arbitrarily
Ambient temperature range ℃
-20…+50
Weight kg
Size 10 8.7
Size 16 10.6
Size 25 18.4
Size 35 81
Related products
Packing&Shipping
In order to ensure that the product is not damaged during transportation, we will choose to use high-hardness cardboard boxes or wooden boxes to package the product according to the volume of the product, and adopt protective measures such as foamanti-collision and wooden frame fixing to ensure the safe and non-destructive delivery of the goods to the greatest extent.
