FSF Cables 19awg -26awg ANSI/ICEA S-84-608-2011 RDUP 7 CFR 1755.890 (PE-89)

Specifications:

1.Conductor :Solid annealed copper

2.Insulation:Dual insulation consisting of an inner layer of foamed, natural polyolefin over which is applied a solid (skin) layer of polyolefin colored in accordance with industry standards

3.Twisted Pairs:Individual insulated conductors; twisted into pairs with varying lay lengths; specific color combinations provide pair identification

4.≤ 25-Pair Core: Pairs are assembled into a cylindrical core

5.> 25-Pair Core: Cables larger than 25-pair are assembled into units, which are then used to assemble the core; units

are identifiable using color-coded binders

6.Filling Compound:80°C ETPR compound, completely filling the interstices between the pairs and under the core wrap

7.Core Wrap : Non-hygroscopic, dielectric tape applied over the core

8. Shield:Corrugated, copolymer coated, 8 mil aluminum tape applied longitudinally with an overlap; flooded shield interfaces

9.Jacket:Black, polyethylene

10.Jacket Marking:Identifying information includes a telephone handset, cable code, pair count, AWG, date of manufacture and sequential length markings at 2 foot intervals

Standard :

ANSI/ICEA S-84-608-2011

RDUP 7 CFR 1755.890 (PE-89)

Application

• Low risk direct burial

• Underground conduit

• Lashed aerial

FSF Cables 19awg -26awg ANSI/ICEA S-84-608-2011 RDUP 7 CFR 17

1,100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.

FSF Cables 19awg -26awg ANSI/ICEA S-84-608-2011 RDUP 7 CFR 17

1. We guarantee to offer new advanced goods.

2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction,installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing, If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.

3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.

4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.

Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,and domestic& international trade.
