Item name: Rubber cabtire cable 2PNCT 1 x 2SQ 4*3.5mm2 0.6/1kv elevator drum reel submersible pump EPR rubber cable PCP sheath
Constructure
Conductor: Flexible Class5 Tinned class5 Copper to be BS6360
Insulation: Ethlylene Propylene Rubber (E.P.R). , Type EI 4 to BS 7655
Sheath: CR Rubber Type EM2 to BS 7655
Technical Data
Voltage: 0.6/1kV H-Harmonised Approval
Test voltage:3500V 7-450/750Rated
Operating Temperature range:-20℃+85℃ R-Natural or synthetic Rubber
Bending Radius :15xcable Diameter N-Polychloroprene(PCP Neoprene)
F-Flexible stranded condctor
| 1 Core: | Black |
| 2 Core: | Brown, Blue |
| 3 Core: | Green/yellow, Brown, Blue |
| 4 Core: | Green/Yellow, Black, Blue, Brown |
| 5 Core: | Green/Yellow, Black, Blue, Brown, Black |
Rubber cabtire cable 2PNCT 1 x 2SQ 4*3.5mm2 0.6/1kv elevator drum reel submersible pump EPR rubber cable PCP sheath
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2.By standard wooden drum or roll.
3.Drum size:1100mm*1100mm*1100mm.
or as your request.
Rubber cabtire cable 2PNCT 1 x 2SQ 4*3.5mm2 0.6/1kv elevator drum reel submersible pump EPR rubber cable PCP sheath
Advanced connectors & assembly cables machines and testing equipments.
Large production capacity, short delivery.
Strict QC checking before delivery.
OEM/ODM service available, help you on designing.
Prompt quotation for your inquiry.
More than 10 years experiences in cable and wire field.
Professional connector and cable manufacturer, with good quality and competitive price.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production,
research & development,and domestic& international trade.
Established year: 1988
Total asset: USD 32 million
Plant area: 30000 m2
Number of staff: 380
Engineer:20
Laboratory Inspector: 18
Production line: 18
Testing machine:25
Producing capacity each year: 320000 km .
Rubber cabtire cable 2PNCT 1 x 2SQ 4*3.5mm2 0.6/1kv elevator drum reel submersible pump EPR rubber cable PCP sheath standard:
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on.
Meanwhile we can produce based on customers' requirements and specifications.
Rubber cabtire cable 2PNCT 1 x 2SQ 4*3.5mm2 0.6/1kv elevator drum reel submersible pump EPR rubber cable PCP sheath Certificate:
The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical
Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation
of Urban and Rural Power Grid Construction.
1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
