ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores
ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores
Single of multi-wire conductors of plain copper wires, xlpe core insulation, cores twice concentrically according to IEC60502, common core sheathing, outer sheath of PVC standard colour black, flame retardant.
Technical Data
- Minimum bending radius for single core : 15 x outer diameter
- Minimum bending radius for multi core : 12 x outer diameter
- re = round conductor, single wire
- rm = round conductor, multi wire
- sm = sectorial conductor
|
1st class |
0.6/1 |
1.8/3 |
3.6/6 |
6/10 |
8.7/15 |
12/20 |
18/30 |
21/35 |
|||
2nd class |
1/1 |
3/3 |
6/6 |
8.7/10 |
12/15 |
18/20 |
- |
26/35 |
||||
1 Core |
Section area(mm2) |
1.5-800 |
25-800 |
25-800 |
25-800 |
35-800 |
50-800 |
50-800 |
50-800 |
|||
2 Core |
Section Area(mm2) |
1.5-185 |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
|||
3 Core |
Section area(mm2) |
1.5-400 |
25-400 |
25-400 |
25-400 |
35-400 |
50-400 |
50-400 |
50-400 |
|||
4 Core |
Section Area(mm2) |
2.5-400 |
25-400 |
/ |
/ |
/ |
/ |
/ |
/ |
|||
5 Core |
Section area(mm2) |
2.5-400 |
25-400 |
/ |
/ |
/ |
/ |
/ |
/ |
ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores
1. wooden drum, Iron wooden drum or as your request
2. the long & wide & high of 20 size container:5.95*2.32*2.3 meter.
3. the long & wide & high of 40 size container:11.9*2.32*2.72.
ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores
Large production capacity, short delivery.
Strict QC checking before delivery.
OEM/ODM service available, help you on designing.
Prompt quotation for your inquiry.
More than 10 years experiences in cable and wire field.
Professional connector and cable manufacturer, with good quality and competitive price.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production,
research & development,and domestic& international trade.
Established year: 1988
Total asset: USD 32 million
Plant area: 30000 m2
Number of staff: 380
Engineer:20
Laboratory Inspector: 18
Production line: 18
Testing machine:25
Producing capacity each year: 320000 km
ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores Standard.
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on. Meanwhile we can produce based on customers' requirements and specifications.
ACEFLEX RVK 0.6/1KV cu/xlpe/fr-pvc power cable Flame retardant unarmoured power cable flexible copper single 2 3 4 cores Certification.
The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
