( br) Low Voltage Power Cable 4C x 185 SQ MM AL XLPE Armoured Cable.
1,Item name: Low Voltage Power Cable 4C x 185 SQ MM AL XLPE Armoured Cable.
2. Low Voltage Power Cable 4C x 185 SQ MM AL XLPE Armoured Cable Operating Characteristics.
Rated voltage: 0.6/1(1.2)kV
Max. permissible continuous operating temperature of conductor: 70°C
Max. temperature of conductor during short-circuit (5s max. duration) shall not exceed:
Nominal cross section of conductor ≤300mm2: 160 °C
Nominal cross section of conductor >300mm2: 140 °C
The ambient temperature under installation should not be lower than: 0 °C
The bending radius of cable is recommended as following:
For single core cable: not less than 15 times of the diameter of cable
For multi-core cable: not less than 12 times of the diameter of cable
When the armored single core cable used for Alternative Current(AC) system, the armoring material should be non-magnetic.
3. Low Voltage Power Cable 4C x 185 SQ MM AL XLPE Armoured Cable Description
|
Chinese Type |
Description |
Core qty |
Conductors range |
VV22 |
Copper conductor, PVC insulation, Double galvanized Steel Tape Armored, PVC outer sheath Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
VV23 |
Copper conductor, PVC insulation, Double galvanized Steel Tape Armored, PE outer sheath Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
ZA-VV22 ZB-VV22 ZC-VV22 |
Copper conductor, PVC insulation, Double galvanized Steel Tape Armored flame-retardant Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~630mm2 |
NH-VV22 |
Copper conductor, PVC insulation, Double galvanized steel Tape Armored fire-resistant Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
Cable size |
Conductor type |
Nominal thickness of PVC insulation (mm) |
Nominal thickness of steel tape(mm) |
Nominal thickness of PVC sheath(mm) |
Approx. cable overall diameter (mm) |
Max. D.C resistance @ 200C (Ω/km) |
4x1.5mm2 |
RE or RM |
0.8 |
0.2 |
1.8 |
14.2 |
12.1 |
4x2.5mm2 |
RE or RM |
0.8 |
0.2 |
1.8 |
15.1 |
7.41 |
4x4mm2 |
RE or RM |
1.0 |
0.2 |
1.8 |
17.2 |
4.61 |
4x6mm2 |
RE or RM |
1.0 |
0.2 |
1.8 |
18.5 |
3.08 |
4x10mm2 |
RM |
1.0 |
0.2 |
1.8 |
21.6 |
1.83 |
4x16mm2 |
RM |
1.0 |
0.2 |
1.8 |
24.1 |
1.15 |
4x25mm2 |
SM |
1.2 |
0.2 |
1.8 |
23.8 |
0.727 |
4x35mm2 |
SM |
1.2 |
0.2 |
1.8 |
25.9 |
0.524 |
4x50mm2 |
SM |
1.4 |
0.5 |
2.0 |
31.4 |
0.387 |
4x70mm2 |
SM |
1.4 |
0.5 |
2.1 |
35.0 |
0.268 |
4x95mm2 |
SM |
1.6 |
0.5 |
2.3 |
39.9 |
0.193 |
4x120mm2 |
SM |
1.6 |
0.5 |
2.4 |
43.1 |
0.153 |
4x150mm2 |
SM |
1.8 |
0.5 |
2.6 |
47.3 |
0.124 |
4x185mm2 |
SM |
2.0 |
0.5 |
2.8 |
52.3 |
0.0991 |
4x240mm2 |
SM |
2.2 |
0.5 |
3.0 |
58.4 |
0.0754 |
4x300mm2 |
SM |
2.4 |
0.5 |
3.2 |
64.3 |
0.0601 |
Low Voltage Power Cable 4C x 185 SQ MM AL XLPE Armoured Cable packging is:
The cable packed in steel-wooden drum.
Our Principles:
1)Quality first, customer first, safety first
2)Better service, faster delivery
3)Equal and mutual benefit
4)Honesty and profession
Our service:
1.Swift and professional response
2.Patient and trusty
3.Severe quality control system
4.On-time delivery
Our Mission:
Supply quality products with competitive price & excellent service
Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production,
research & development,and domestic & international trade.
The company has passed ISO9001-2008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification,
State Construction and Project Commitee Recommended Manufacturer of the Transformation of Urban
and Rural Power Grid Construction.
1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
