LED Linear Light LL-LC1 Series White LED Linear Light manufacturer Customized LED Linear Light supplier
Model: JST-LL-JC1
Wattage: 3W-35W
LED Chip: OSRAM5050
Driver Brand: OSRAM/Philips/Lifud
RA: ＞90
Finish Color: White/Black/Customized
Beam Angle: 15°/24°/38°/50°/50x50°/70x70°/35x70°
Diameter: 51mm-393mm
Cutout: 46mm-390mm
Description
LED Linear Light LL-JC1 Series the lamp body, in fashionable design,is made of 6063 section aluminum and PC reflector. It is combined LED lighting with building harmoniously. Creat a circle of light from a line of LED downlights, A narrow line of nano LED downlights for pure minimalism, seven choices of beam angle 15°/24°/38°/50°/50x50°/70x70°/35x70°, Brilliant quality, more than 50,000 hours life span.
Advantages
. Creat a circle of light from a line of LED Downlights
. A narrow line of nano LED Downlights for pure minimalism
. Superior glare control for high performance and visual comfort
. Seven choices of beam angle 15°/24°/38°/50°/50x50°/70x70°/35x70°
Jarstar-Long lifespan LED Linear Light Specification
Model |
Power |
CRI |
CCT |
PF |
Current |
Input Voltage |
Beam Angle |
Dimension |
Cutout |
JST-LL-JC1 |
3W |
>80/90 |
2700K-5000K |
>0.65 |
0.60A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L51*W51*H56mm |
L46*W46mm |
JST-LL-JC1 |
10W |
>80/90 |
2700K-5000K |
>0.90 |
0.35A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L127*W51*H56mm |
L124*W46mm |
JST-LL-JC1 |
15W |
>80/90 |
2700K-5000K |
>0.90 |
0.40A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L90*W90*H56mm |
L86*W86mm |
JST-LL-JC1 |
20W |
>80/90 |
2700K-5000K |
>0.90 |
0.60A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L203*W51*H56mm |
L200*W46mm |
JST-LL-JC1 |
30W |
>80/90 |
2700K-5000K |
>0.90 |
0.80A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L128*W128*H56mm |
L124*W124mm |
JST-LL-JC1 |
35W |
>80/90 |
2700K-5000K |
>0.90 |
0.90A |
AC220-240V |
15°/24°/38°/50° /50x50°/70x70°/35x70° |
L393*W51*H56mm |
L390*W46mm |
Application
Art galleries, museums, villas, hotels, high-end clubs, bars, exhibition halls.
