NT816Fcommon rail injector test bench fuel injector test bench

NT816F common rail injector test bench

fuel injector test benc

Function introduction

1.High pressure cleaning: high pressure cleaning impurities attached to internal parts of injector.

2.Atomization test: to judge whether the injector is blocked through the atomization effect.

3.Single injection: the operator can set the number of injections to conduct a single injection observation.

4. Sealing test: check the sealing performance of nozzle, nozzle cap nut and solenoid valve.

5. Injector test: Test the injected fuel & return volume under rating, idling, Emission, pre-injection and pre-injection 2 status.

6. Test the current of injector solenoid valve, valve assembly lift, fuel injection lift.
7. Fully automatic test of different types of solenoid valve injector and piezoelectric injector
8. Check,save, print data and customer information.

Main configuration:

1. Equip original Bosch CP1 pump
2. Stainless steel fuel tank with industrial air conditioner to control temperature ± 2 ℃ circularly

3. Equip original German high-precision flow sensor
4. Equip original Bosch DRV, pressure sensor (0-2000bar)
5. Equip Bosch 3rd stage stroke testing program and adapters

6. Include DRV, fuel injection cooling treatment device
7. Include Oil circuit emptying treatment device
8. You can set the injection current curve by yourselves
9. The system includes original fuel injector current curve and data
10. Main motor power 5.5KW, optional three phases 380V 50HZ, three phases 220V 60HZ, two phases 220V/60Hz in convenient for the different need of power supply in different countries.
