CR926 CR825 Common Rail Diesel Fuel Common Rail Test Bench cr 926
US$ 13,000 - 16,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BEACON
Place of Origin:
Shandong, China
Model Number:
cr926
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or any sea port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Pressure Injection Test Bench CR926, for CR Injector and Pump, EUI/EUP, HEUIUS$ 13,000 - 16,000MOQ: 1 Set -
EPS208 EPS205 EPS200 Common Rail Diesel Fuel Injector TesterUS$ 2,500 - 3,000MOQ: 1 Set
-
Auto Testing Calibration Machine BCS208 Crdi Common Rail Piezo Injector Coding Test Bench EPS208US$ 2,500 - 3,000MOQ: 1 Set
-
EPS208 Common Rail Diesel Fuel Injector Test Bench Common Rail Injector Coding QR IMA ISA IQA ISX Encoding Test BenchUS$ 2,500 - 3,000MOQ: 1 Set
-
EPS208 Cri Injector Repair Machine Common Rail Diesel Injector Test EquipmentUS$ 2,500 - 3,000MOQ: 1 Set
Brand Name
BEACON
Place of Origin
Shandong, China
Model Number
cr926
Power
Electronic
CR926 CR825 Common rail Diesel fuel common rail test bench cr 926
whatsapp/wechat:008617705388613
CR926 is the latest independent research and development product of Beacon in 2020, which has high operability, practicality and economy. Is your best choice.
Product Description
Main function
The control system of the diesel electric injection integrated machine adopts full automatic control, which can be very convenient for common rail solenoid valve or piezoelectric injector, high pressure pump, HEUI medium pressure common rail injector, actuation pump, 320D oil pump, monomer Maintenance testing of pumps and pump nozzles. Thousands of types and models of EFI injectors, oil pumps, including Bosch, Delphi, Denso, Siemens, Caterpillar, Cummins, etc., can be tested with complete experimental data.
Main functional characteristics
(1) All-in-one fully automatic operation, including test bed speed, rail pressure, flow measurement, report analysis, etc., one-click operation, you can get the measurement results.
(2) Can test Bosch, Delphi, Denso, Siemens, Caterpillar, Cummins, domestic fresh air, Beiyou heavy oil and other manufacturers of solenoid valve type or piezoelectric crystal type injectors, common rail high pressure pumps,
(3) Can test Bosch, Caterpillar, Cummins, Delphi, Nanyue Hengyang, Witt and other monomer pumps and pump nozzles
(4) Can test HEUI medium pressure common rail injector,
(5) Caterpillar 320D high-pressure pump can be tested
(6) Can test VP37, VP44
(7) Test actuation pump, PT pump
(8) The test standard data is consistent with the original factory data, and the test accuracy reaches the original factory standard;
(9) The database is fully open and the part number can be increased.
(10) The network is automatically upgraded, and the test data and functions are kept up to date
Technical parameters
Main motor |
11KW~15KW |
11KW~15KW |
||||
Diesel Pump |
10ML |
10ML |
||||
Oil pump |
10ML |
10ML |
||||
Diesel tank volume (liter) |
44L |
44L |
||||
Engine oil tank volume (liter) |
32L |
32L |
||||
Pressure (Mpa) |
0~250 |
0~250 |
||||
Test bench dimensions (mm) (length × width × height) |
2120×1340×1950 |
2120×1340×1950mm |
||||
Test bench weight (kg) |
About 1500 |
About 1500 kg |
||||
Best new common rail test system:
With Injector QR coding,for BOSCH DENSO DELPHI SIEMENS:
CAMBOX + ADAPTOR
Full set EUI EUP tester+ CAMBOX+ adaptor for electronic unit injector EUI EUP injector test
With CAT Actuating pump and CAT 320D pump test ,check the flange(adaptor as below):
HEUI fixture
ACCESSORIES:
Packing & Delivery
Certifications
Company Profile
JINAN BEACON MACHINE CO.,LTD is a leading manufacturer in China specialized in researching and developing diesel injection pump test bench and turbocharger balancing machine .
Our products are exported to more than 100 countries .Due to our excellent quality, competitive price and professional technical support, our products are the common choice of many overseas buyers.
Our main product include:
common rail injector/pump test bench ,
common rail injector/pump tester (CRDI),
diesel injection pump test bench EUI/EUP tester cam box ,
Denso ECD-V3 ,V4, V5 pump tester ,
PT Cummings pump and injector tester ,
common rail tools
High quality spare parts: Injector/valve/nozzle/head rotor/plunger....
Welcome to visit our factory and cooperate in the future.
