Help CenterNT816F Nant Common Rail Injector Test Bench 3 Stage Measuring Function Common Rail Injector Test Bench
Related Products
-
Hot Sale CRS6000 Diesel Injector Calibration Machine Common Rail Injector Test Bench Crs5000/crs-6000US$ 2,300 - 2,700MOQ: 1 Set -
Original EPS200 EPS205 Crdi Common Rail Injector Test BenchUS$ 10,500 - 15,000MOQ: 1 Set
-
JINAN BEACON CRS6000 Diesel Fuel Injector Calibration Machine Common Rail Injector Test Bench Crs5000/crs-6000US$ 2,300 - 2,700MOQ: 1 Set
-
CRS6000 2600 Bar Electronic Injector Test Diesel Fuel Injector Common Rail cr Injector Test BenchUS$ 2,900 - 3,200MOQ: 1 Set
-
Diesel Fuel Injector Test Bench CRS6000 Common Rail CR Cum.mins Injector Test High Pressure 2600 Bar cr Injector Test BenchUS$ 2,900 - 3,200MOQ: 1 Set
Function introduction:
1.High pressure cleaning: high pressure cleaning impurities attached to internal parts of injector.
2.Atomization test: to judge whether the injector is blocked through the atomization effect.
3.Single injection: the operator can set the number of injections to conduct a single injection observation.
4. Sealing test: check the sealing performance of nozzle, nozzle cap nut and solenoid valve.
5. Injector test: Test the injected fuel & return volume under rating, idling, Emission, pre-injection and pre- injection 2
status.
6. Test the current of injector solenoid valve, valve assembly lift, fuel injection lift.
7. Fully automatic test of different types of solenoid valve injector and piezoelectric injector
8. Check,save, print data and customer information.
Main configuration:
2. Stainless steel fuel tank with industrial air conditioner to control temperature ± 2 ℃ circularly
3. Equip original German high-precision flow sensor
4. Equip original Bosch DRV, pressure sensor (0-2000bar)
5. Equip Bosch 3rd stage stroke testing program and adapters
6. Include DRV, fuel injection cooling treatment device
7. Include Oil circuit emptying treatment device
8. You can set the injection current curve by yourselves
9. The system includes original fuel injector current curve and data
10. Main motor power 5.5KW, optional three phases 380V 50HZ, three phases 220V 60HZ, two phases 220V/60Hz in convenient for the different need of power supply in different countries.
System advantage:
2. Industrial computer system control, high-speed operation, stable performance
3. Equip original Bosch data, test accuracy similar with the world-leading test bench.
4. Powerful database: include more than 1,000 kinds of Bosch, Delphi, Denso, Siemens injector plan,
and test plan could be updated free of charge
5. Injector database management: edit,save, revise and delete
6. The operator can choose to test step by step or continuous test
7. The operator can set injection time and injection pressure during testing
8. The operator can choose testing results automatically judged by computer system or judge it by yourself.
9. Include Chinese, English, German, Spanish, French, Russian and Portuguese operating interface
10. Support customized products and application.
voltage |
380v/220v |
||||
Common rail injector database: |
Over 2600 injector database |
||||
JINAN BEACON MACHINE CO.,LTD is a leading manufacturer in China specialized in researching and developing diesel injection pump test bench and turbocharger balancing machine .
Our products are exported to more than 100 countries .Due to our excellent quality, competitive price and professional technical support, our products are the common choice of many overseas buyers.
Our main product include:
common rail injector/pump test bench ,
common rail injector/pump tester (CRDI),
diesel injection pump test bench EUI/EUP tester cam box ,
Denso ECD-V3 ,V4, V5 pump tester ,
PT Cummings pump and injector tester ,
common rail tools
High quality spare parts: Injector/valve/nozzle/head rotor/plunger....
Welcome to visit our factory and cooperate in the future.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 7-14 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
