CR918S injector coding PT injector pump test boten common rail pump and injector test bench

Name: CR918S injector coding PT injector pump test boten common rail pump and injector test bench
Brand: BEACON
Price: USD $18,999 - 22,999 / Set

FOB Price

USD $18,999 - $22,999 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao or any China port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	BEACON	Place of Origin:	Shandong, China	Model Number:	CR918s
Power:	Electronic

Product Description

CR918S injector coding PT injector pump test boten common rail pump and injector test bench

Description:

6 injectors can be triggered at the same time ,and 6 injectors correction codes can be generated simultaneously!

Accurate response time

Generate oil volume correction code

Test PT pump

Test PT injector

Test HPI Q60 X15

Test Cummins HPI Actuator

With high quality EUI EUP CAMBOX and HEUI cat injector adaptor

FEATURES:

Bosch 6,7,8,9,10-digit IMA encoding generation

Bosch piezo injector IMA,ISA encoding generation

DENSO QR oil volume correction code generation

Delphi C2i,C3i encoding generation

Siemens (VDO) ICC code generation

►Test common rail injector

►Test common rail pump

► Test EUI/EUP

►Test the HEUI injector

►Test HEUI actuation pump

►The highest rail pressure is 2600 bar

►Drive motor 22KW

►Injection drive and system voltage monitor

► Common rail with filter function

► Dual DRV configuration

►High pressure filter plugging reminder function

► Waste tank overflow warning

► Oil tank and diesel tank strong integrated air conditioning system

Delphi double plus E 3 function and newest common rail test system:

TECHNICAL PARAMETERS:

Main power			380V/220V
Phase			1/3
Frequency			50/60hz
Current			45A(MAX)
Main Motor			22kw
Main motor rotation			0-4000 RPM/MIN
Oil motor HP/FLOW			0.19KW/13L/MIN
Diesel motor HP/FLOW			0.19KW/13L/MIN
Control circuit voltage			DC12V/24V 350W
ECU internal voltage			0-200V DC(MAX)
Oil tank volume			30L
Diesel Tank volume			52L
Tempreature control			Heating/Forced cooling
Max rail pressure			180Mpa 240Mpa(Optional)

EUI EUP injector accessories list:

Certifications

Product packaging

Company Profile

JINAN BEACON MACHINE CO.,LTD is a leading manufacturer in China specialized in researching and developing diesel injection pump test bench and turbocharger balancing machine .

Our products are exported to more than 100 countries .Due to our excellent quality, competitive price and professional technical support, our products are the common choice of many overseas buyers.

Our main product include:

common rail injector/pump test bench ,

common rail injector/pump tester (CRDI),

diesel injection pump test bench EUI/EUP tester cam box ,

Denso ECD-V3 ,V4, V5 pump tester ,

PT Cummings pump and injector tester ,

common rail tools

High quality spare parts: Injector/valve/nozzle/head rotor/plunger....

Welcome to visit our factory and cooperate in the future.
