CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function

CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-1
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-2
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-3
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-4
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-5
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function thumbnail-6
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-1
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-2
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-3
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-4
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-5
CR918S Diesel Fuel Common Rail Injector Pump Test Calibration Machine With BIP Function photo-6
US$ 20,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BEACON
Place of Origin:
Shandong, China
Model Number:
CR918S
Contact Supplier Request Quote Chat Now
Jinan Beacon Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BEACON
Place of Origin Shandong, China
Model Number CR918S
Power Electronic
Product Description

Automotive fuel pump machine CR918S Common rail diesel fuel injection pump test bench

FEATURES:

1.Test All kinds of common rail injectors
2.Test All kinds of Piezo injectors
3.Test All kinds of common rail pumps
4.Test All kinds of EUI/EUP with BIP functions
5.Test All kinds of HEUI injectors
6.Test All kinds of HEUI actuation pumps
7.Test CAT 320D pump
8.Test Denso HP0 pump
9.The highest rail pressure is 2600 bar
10. Drive motor 22KW
11. Injection drive and system voltage monitor
12. Common rail with filter function
13. Dual DRV configuration
14. High pressure filter plugging reminder function
15.Waste tank overflow warning
16. Oil tank and diesel tank strong integrated air conditioning system

SPECIAL FEATURES:

B osch 6,7,8,9,10-digit IMA encoding generation
B osch piezo injector IMA,ISA encoding generation
D ENSO QR oil volume correction code generation
D elphi C2i,C3i encoding generation
S iemens (VDO) ICC code generation
New optional functions :
+ 6 injectors can be triggered at the same time , and 6 injectors correction codes can be generated simultaneously!
+ Accurate response time
+ Generate oil volume correction code
+ Test PT pump
+ Test PT injector
+ Test HPI Q60 X15
+ Test C ummins HPI Actuator

1. Power:
10. ECU internal voltage
19.Center distance between motor and
380V AC 220V(Optional) 22kw
0-200V DC(MAX)
working bench
2.Phase
11.Oil tank volume
125mm
Three,single(Optional)
30L
20.Weight
3. Frequency
12. Diesel Tank volume
1100KG
50HZ /60HZ
50L
21.Outlook size net
4. Current
13.Tempreature control
(LxWxH)2400x1350x1880
45A(MAX)
Heating/Forced cooling
22.Wooden cage
5.Main motor rotation
14.Max rail pressure
(LxWxH)2500x1480x2050
0-4000 RPM/MIN
180Mpa 240Mpa(Optional)
6. Oil motor HP/FLOW
15.Flowmeter(injection)
0.19KW/13L/MIN
4-550ml/min
7. Temperature of test oil
16.Flowmeter(pump supply)
40±2℃
1-400L/H
8.Diesel motor HP/FLOW
17.Flowmeter(pump flowback)
0.19KW/13L/MIN
1-400L/H
9. Control circuit voltage
18.Flowmeter(oil)
DC12V/24V 350W
5-600L/H
Detailed Image
Our Advantage
Certifications
Packing & Delivery
Our Service
Our Company

JINAN BEACON MACHINE CO.,LTD is a leading manufacturer in China specialized in researching and developing diesel injection pump test bench and turbocharger balancing machine .
Our products are exported to more than 100 countries .Due to our excellent quality, competitive price and professional technical support, our products are the common choice of many overseas buyers.

Our main product include:
common rail injector/pump test bench ,
common rail injector/pump tester (CRDI),
diesel injection pump test bench EUI/EUP tester cam box ,
Denso ECD-V3 ,V4, V5 pump tester ,
PT Cummings pump and injector tester ,
common rail tools
High quality spare parts: Injector/valve/nozzle/head rotor/plunger....

Welcome to visit our factory and cooperate in the future.
