Help CenterCR825 High Pressure Common Rail Injector Pump Test Stand HEUI EUI EUP Injector Coding Test Bench
Related Products
-
Diesel Service CR825 CRS825 Test VP37 VP44 Common Rail Diesel Injector Pump Test BenchUS$ 9,000 - 12,000MOQ: 1 Set -
CR825 Injector Iqa Coding Denso Piezo Common Rail Injector Pump Test BenchUS$ 11,000 - 11,000MOQ: 1 Set
-
BEACON MACHINE CR825 CRDI High Pressure Common Rail Diesel Fuel Injector Pump Test EquipmentUS$ 11,000 - 11,000MOQ: 1 Set
-
BC-CR825 Used Manual Common Rail Diesel Injector Pump Service Machine Test BenchUS$ 9,500 - 11,000MOQ: 1 Set
-
2019 New CR825 Common Rail Diesel Pump Test Machine for All Kinds of CR Injectors and PumpsUS$ 9,500 - 11,000MOQ: 1 Set
MAIN CONFIGURATION:
1.Industrial PC with touch screen
2.Compressor cooling
3.Oil tank(including heating,refrigeration,liquid level detection,temperature detection)
4.Diesel tank(including heating,refrigeration,liquid level detection,temperature detection)
5.Flow meter(German ZDM) detecting the fuel injection flow rate
6.Flow meter(German ZDM) detection of common rail pump
7.Flow meter(German KRACHT) to detect oil flow
8.Flow meter(German KRACHT) detection of diesel oil return flow
9.2sets of BOSCH common rail +DRV
10.Oil tank temperature sensor
11.Diesel fuel tank temperature sensor
12.Diesel supply temperature sensor
13.Diesel return temperature sensor
14.Oil pressure sensor
15.Diesel supply pressure sensor
16.Diesel return pressure sensor
17.Diesel pump internal pressure sensor
18.Oil pressure closed loop control module
19.The device is convenient to move and position the roller
FUNCTION CHARACTERISTIC:
1.Test all the manufacturers of common rail injector
2.Test all the manufacturers of piezo injector
3.Test all the manufacturers of common rail pump
4.Test DENSO HP0 pump
5.Test CAT common rail (HEUI) injector
6.Test CAT common rail (HEUI) engine oil pump
7.Test CAT 320D common rail pump (the world's first successful development)
8.Test EUI/EUP (can adjust the lift but not to change the camshaft)
9.Test VP44 VE VP37 pump optional function
10.Test RED3 RED4 TICS ZEXEL electronic control pump optional function
11.Drive circuit board(solenold valve electric parameters to enhance the voltage current,time,pull in voltage ,current,time,keep voltage ,current,time,according to the setting of parameters of production factory)
12.Accept the speed sensor ,encode signal,high speed solenoid valve drive signal.Accept the speed sensor ,encoder signal,output 2 PWM drive signal, 2 way solenoid valve drive signal,1 high speed solenoid valve drive signal.
Driving signal waveform can be programed.
Note: this prroduct can only delivery by sea shipping,before start the order,please let us know your sea port name,thanks.
Highlight function:
Cable board:
Multi-function support,for pvc,pvc2 piezo,drv,measuring unit,etc....
Flow sensor:
5-24v DC 200ma flow sensor
Fuel tank:
With two fuel tank,one is for diesel fuel,one is for engine oil.
System:
Newest and best common rail test system with latest upgrade.
We can customize different color as your request:
JINAN BEACON MACHINE CO.,LTD is a leading manufacturer in China specialized in researching and developing diesel injection pump test bench and turbocharger balancing machine .
Our products are exported to more than 100 countries .Due to our excellent quality, competitive price and professional technical support, our products are the common choice of many overseas buyers.
Our main product include:
common rail injector/pump test bench ,
common rail injector/pump tester (CRDI),
diesel injection pump test bench EUI/EUP tester cam box ,
Denso ECD-V3 ,V4, V5 pump tester ,
PT Cummings pump and injector tester ,
common rail tools
High quality spare parts: Injector/valve/nozzle/head rotor/plunger....
Welcome to visit our factory and cooperate in the future.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 7-14 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
