Brand Name ACREL
Place of Origin China
Model Number AMC72L-E4/KC
Operating Temperature -10~55
Dimensions 75*75mm
Measuring Voltage Range ~9999~+9999
Measuring Current Range 0-999999
Accuracy Class 0.5



General

AMC Series electric energy meter

AMC72L-E4/KC intelligent power collection and monitoring device

      Adopting AC sampling technology, can measure many single phase or three phase grid electrical parameters such as current, voltage, power, electric energy etc. directly or indirectly. It can be used for local display, and also can be connected with the control equipment to form measuring and controlling system.
      Fitted with RS-485 communication port, adopting Modbus-RTU protocol. Meters can switch electric parameter signal into standard analog output, with four-channel (two-channel) switching input / two-channel switching output. Based on different requirements, by keys on the faceplate, electric parameters for transformation ratio, alarm, communication etc. can be set up and controlled.










Technical Parameters
Value
Input
Connection
Single phase-2 wire,3 phase-3 wire,3 phase 4-wire
Frequency
45-65Hz
Voltage
Rating:
Single-phase:AC 100V、400V
Three-phase:AC 3x57.7V/100V(100V)、3x220V/380V(400V)
3x380V/660V(660V)(96 size only)
Note:72 profile not suitable for high voltage application
Overload:1.2 fold rating(continuous):2 fold rating for 1 second
Power consumption:＜0.5VA
Current
Rating:AC 1A、5A
Overload:1.2 fold rating(continuous):10 fold rating for 1 second
Power consumption:＜0.5VA
Output
Electric energy
Output mode:open-collector photo-coupler pulse
Pulse constant:10000imp/kWh(settable),see wiring diagram for details
Communication
RS485 port,Modbus-RTU protocol,DLT645 protocol(versions 09 and 97),baud rate 1200-38400
Function
Switching input
Dry contact input,built-in power supply
Switching output
Output mode:Relay normally open contact output
Contact capacity:AC 250V/3A、DC 30V/3A
Analog output
1-5V,4-20mA
Accuracy Class
Frequency:0.05Hz,Current、Voltage;0.2 class,Reactive
Power:1.0 class,Reactice Electric energy:1.0 class active
Power:0.5 class,active electric energy:0.5 class,2-31th harmonic
measurement:±1%
Power Supply
AC/DC 85-265V Power consumption≤10VA
Security
Power frequency
withstand voltage
Between Power supply//Switching Output//Current input//voltage input and
Transmitting//Communication//Pulse Output//switching input AC 2kV 1min;
Between Power supply、switching output、Current input、voltage input AC 2kV 1min;
Between Transmitting、Communication、Pulse Output、switching input AC 1kV 1 min;
Insulation resistance
Input、Output end to machine enclosure＞100MΩ
Environment
Temperature
work:-25℃~+65℃ storage:-40℃~+80℃
Humidity
≤93%RH Non-condensing
Altitude
≤2500m
Wiring





Typical connection

 LCD AMC72L-E4/KC 3P4W wire power meter AMC72L-E4/KC with rs485







Shipping

 LCD AMC72L-E4/KC 3P4W wire power meter AMC72L-E4/KC with rs485
