A rotary type batch cooking pulping equipment. It is spherical in shape and consists mainly of a sphere, a frame, and a transmission. The ball is made of steel plate welded or riveted. There is a loading hole in the vertical centerline of the sphere for loading and feeding into cooking liquids. The steam for cooking heating and the draining of condensate are introduced from the hollow journal. It is used in small and medium-sized straw paper mills.
Technical Parameters
Product name |
Spherical digester |
Nominal volume |
25Cube |
Sphere diameter |
3650mm |
Design pressure |
0.85Mpa |
Design temperature |
200degree |
Hydrostatic test |
1.26Mpa |
Working pressure |
0.8Mpa |
Sphere speed |
0.48r/min |
Motor Model Power |
5.5kw |
Dimension(L*W*H) |
Packaging & Shipping
Packing: Products will packaged according to their shapes, weight, transport distance and transport modes. Large machines will be packaged in sections. Every part export machinery will be in standard export packgae seaworthy wooden case waterproof film, straw rope, carton box etc.
Our Services
Advantage: Company Information
Our company was founded in 1985,according to the modern enterprise mechanism into a large-scale standardized joint-stock enterprises,with 278 workers,including 23 engineers and technicians,15 senior engineers.In general,Aotian is in the leading place of paper making industry in China. Our factory can produce mechanical pulping equipment,chemical pulping equipment,paper scrap deinking equipment, pulping and paer making sewage treatment equipment,paper-plastic of composite paper separating equipment,etc. We will provide whole services according to our clients' demand, like technical design, equipment priduction, installation and test instruction and so on.We will meet and exceed your expectations.Please contact our custom services for details.
Our Exhibition
We go to world famous exhibitions every year. Constantly promote and publicize the company's brand, to the majority of customers to show the strength and image of the company.The high concentration of visitor flow, information flow and capital flow in the exhibition can help our company learn from each other and improve its competitiveness.
Certifications
The company has passed ISO9001:2000 international quality management system certification, self-supporting and export rights. Contact me
Any questions youcan contact me,please click here!
|
