| Frequency 50 Hz | Frequency 60 Hz | ||
|---|---|---|---|
| Connection | D / Y | D / Y | YY / Y or DD / D |
| Standard voltages V | 230/400 V or 400/690 | 220 / 380 or 380 / 660, 254 / 440, 266 / 460 or 277 / 480 | 220 / 440, 230 / 460 |
| IE3 global motor Standard voltages V | 220 – 240 / 380 – 415, 220 – 230 / 380 – 400 or 380 – 400 / 660 – 690 | 254 – 277 / 440 – 480 or 254 – 266 / 440 – 460 | |
| IE grade | Number of poles | Motor type Size | at frequency of 50 Hz | at frequencies of 60 Hz and 50/60 Hz | |
|---|---|---|---|---|---|
| Power kW | Power kW | Power hp | |||
| IE1 | 2-pole | DR2S.. 56 – 80 | 0.18 – 1.5 | 0.18 – 1.5 | 0.25 – 2 |
| 4-pole | 0.09 – 1.1 | 0.09 – 1.1 | 0.10 – 1.5 | ||
| 6-pole | 0.09 – 0.55 | 0.09 – 0.55 | 0.10 – 0.75 | ||
| IE1 | 2-pole | DR2S.. 71 - 132 | 0.37 – 9.2 | 0.37 – 9.2 | 0.50 – 12.3 |
| 4-pole | DR2S.. 71 - 315 | 0.18 – 200 | 0.18 – 200 | 0.25 – 225 | |
| 6-pole | DR2S.. 71 - 160 | 0.25 – 7.5 | 0.25 – 7.5 | 0.33 – 10 | |
| IE2 | 4-pole | DRE..J 71 – 100 | 0.37 – 5.5 | – | – |
| IE3 | 2-pole | DRN.. 63 - 132 | 0.18 – 7.5 | 0.18 – 7.5 | 0.25 – 10 |
| 4-pole | DRN.. 63 - 315 | 0.12 – 200 | 0.12 – 225 | 0.15 – 300 | |
| 6-pole | DRN.. 63 - 160 | 0.09 – 7.5 | 0.09 – 7.5 | 0.10 – 10 | |
| 8-pole | DRN.. 71 - 80 | 0.09 – 0.25 | 0.09 – 0.25 | 0.10 – 0.34 | |
| IE4 | 4-pole | DRU...J | 0.18 – 4 | – | – |
| Energy efficiency specifications on the nameplate |
| ||||
| Additional information on the nameplate |
| ||||
