K Series Helical Bevel Geared Motor Speed Reducer Reduction Gearbox

K Series Helical Bevel Geared Motor Speed Reducer Reduction Gearbox thumbnail-1
K Series Helical Bevel Geared Motor Speed Reducer Reduction Gearbox photo-1
US$ 100 - 1000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
FLYING
Place of Origin:
China
Model Number:
K37~K187
Contact Supplier Request Quote Chat Now
Luan Flying Machinery Co. Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI, NINGBO
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FLYING
Place of Origin China
Model Number K37~K187
Rated Power 0.12-200 Kw
Output Speed 0.15~270rpm
Input Speed 1500rpm
Output Torque Top to 50000nm
Gearing Arrangement Helical

Specifications:

  1. Wide range of ratios
    2. Foot Mounted / B5 or B14 Flanged Mounted / Solid or Hollow Shaft/ Hollow Shaft with Keyed Connection / Shrink Disk / Splined Hollow Shaft
    3. MOQ: 1 set
    4. Competitive Price+ Fast Delivery

    Features:
    1. Can be matched with different type of motor or power for input Convenient for combination connect of different type of machines.
    2. High transmission efficiency, can up to 96% for a single machine
    3. Precise Division of transmission ratio with a wide range, machine combination can produce a large ratio which with a very low output speed rotate
    4. Designed for foot, Shaft and flanged installation




  3. Technical data:
    1, Output torque: 200-50000(N. M)
    2, Rated power: 0.12-200(kw)
    3, Input speed: ≤ 1500 (rpm)
    4, Output speed: ≤ 280(rpm)
    5, Transmission ratio: ≥ 5.36
    6, Series: 3
    7, Install form: M1-M6
    8, Model No.: K/KA/KF/KAF/KH/KHF/KV/KVF/KVZ(37/47/57/67/77/87/97/107/127/157/167/187)

Version Size
37 47 57 67 77 87
K.. Foot-mounted K37 K47 K57 K67 K77 K87
KA..B Foot-mounted / Hollow shaft KA37B KA47B KA57B KA67B KA77B KA87B
KV..B Foot-mounted / Hollow shaft / Splined hollow shaft KV37B KV47B KV57B KV67B KV77B KV87B
KH..B Foot-mounted / Hollow shaft / Shrink disk KH37B KH47B KH57B KH67B KH77B KH87B
KF.. B5 Flange-mounted KF37 KF47 KF57 KF67 KF77 KF87
KAF.. B5 Flange-mounted / Hollow shaft KAF37 KAF47 KAF57 KAF67 KAF77 KAF87
KVF.. B5 Flange-mounted / Hollow shaft / Splined hollow shaft KVF37 KVF47 KVF57 KVF67 KVF77 KVF87
KHF.. B5 Flange-mounted / Hollow shaft / Shrink disk KHF37 KHF47 KHF57 KHF67 KHF77 KHF87
KA.. Hollow shaft KA37 KA47 KA57 KA67 KA77 KA87
KV.. Hollow shaft / Splined hollow shaft KV37 KV47 KV57 KV67 KV77 KV87
KH.. Hollow shaft / Shrink disk KH37 KH47 KH57 KH67 KH77 KH87
KT.. Hollow shaft  KT37 KT47 KT57 KT67 KT77 KT87
KAZ.. B14 Flange-mounted / Hollow shaft KAZ37 KAZ47 KAZ57 KAZ67 KAZ77 KAZ87
KVZ.. B14 Flange-mounted / Hollow shaft / Splined hollow shaft KVZ37 KVZ47 KVZ57 KVZ67 KVZ77 KVZ87
KHZ.. B14 Flange-mounted / Hollow shaft / Shrink disk KHZ37 KHZ47 KHZ57 KHZ67 KHZ77 KHZ87
Version Size
97 107 127 157 167 187
K.. Foot-mounted K97 K107 K127 K157 K167 K187
KA..B Foot-mounted / Hollow shaft KA97B KA107B KA127B KA157B KA167B KA187B
KV..B Foot-mounted / Hollow shaft / Splined hollow shaft KV97B KV107B KV127B KV157B KV167B KV187B
KH..B Foot-mounted / Hollow shaft / Shrink disk KH97B KH107B KH127B KH157B KH167B KH187B
KF.. B5 Flange-mounted KF97 KF107 KF127 KF157 KF167 KF187
KAF.. B5 Flange-mounted / Hollow shaft KAF97 KAF107 KAF127 KAF157

KVF.. B5 Flange-mounted / Hollow shaft / Splined hollow shaft KVF97 KVF107 KVF127 KVF157 KVF167 KVF187
KHF.. B5 Flange-mounted / Hollow shaft / Shrink disk KHF97 KHF107 KHF127 KHF157 KHF167 KHF187
KA.. Hollow shaft KA97 KA107 KA127 KA157 KA167 KA187
KV.. Hollow shaft / Splined hollow shaft KV97 KV107 KV127 KV157 KV167 KV187
KH.. Hollow shaft / Shrink disk KH97 KH107 KH127 KH157 KH167 KH187
KT.. Hollow shaft  KT97 KT107 KT127 KT157 KT167 KT187
KAZ.. B14 Flange-mounted / Hollow shaft KAZ97 KAZ107 KAZ127 KAZ157 KAZ167 KAZ187
KVZ.. B14 Flange-mounted / Hollow shaft / Splined hollow shaft KVZ97 KVZ107 KVZ127 KVZ157 KVZ167 KVZ187
KHZ.. B14 Flange-mounted / Hollow shaft / Shrink disk KHZ97 KHZ107 KHZ127 KHZ157 KHZ167 KHZ187

Product Tags: helical bevel gearmotor , right angle gearbox , 90 degree gear box , transmission gear box , reduction gearbox , conveyor gearmotor , speed reducer , SEW K series , reduction gears
