16mm 3 Core Power Cable for Tower Crane

products description

Various of flame-retardant and non-flame retardant cable can be manufactured with three technology(peroxide, silane and irradiation crosslinking). The flame-retardant cable covers all kinds of low-smoke low-halogen low-smoke halogen free, and non-smoke nonhalogented and three classes of A, B, C.

1). Standard: IEC60502

Our cable can be manufactured according to companys specification which is equivalent to IEC 60502, IEC 60332, and IEC 60754.

(2). The rated voltages

U0/U(Um) of the cables considered in this standard are as follows:

U0/U(Um) =0.6/1KV  3.6/6(7.2)-6/10(12)-8.7/15(17.5)-12/20(24)-18/30(36)KV


3). Detail Description or Construction:

Conductor: Solid or stranded copper
Insulation: Cross-linked polyethylene (XLPE) or Polyvinyl chloride (PVC)
Filler: Polypropylene filament with lapped binding tape
Binder: Binding tape
Inner sheath: Polyvinyl chloride (PVC)
Amour: Galvanized steel wire armored(SWA) or steel tape armored(STA)
Sheath: Polyvinyl chloride (PVC)
cross-section area can be up to 400 sqmm (copper or aluminiun conductor). Conductor long-time operating temperature is 90 degrees. In short circuit, conductor highest temperature should be not more than 250 degrees.

4). Application: Tower Crane and Passenger Hoist

5). Marking: According to the customer

6). Installation: CU/XLPE/SWA/PVC and CU/PVC/SWA/PVC power cable can be installed in air, duct, conduit or direct burial. It is recommended that the installation instructions indicated by the Local Electric Code, or any equivalent, be followed, so that the safeguarding of persons and the integrity of the product will not be affected by deficiencies in the installation

7). Properties and functions:
The cable is extruding weather ability XLPE insulation,weather ability HDPE insulation or black weather ability PVC insulation out of the compacting

Simple construction, good mechanical, physical and electrical properties, enough safety, it also has good properties of resistance to tracking, surface discharge resistance, resistance to weathering. It has smaller laying distance, line length, voltage drop when comparing with bare wire, especially in reducing accident and ensuring safety of the body. The cable can be used in city, country, mountain area, forest area, mining area, and is an all-weather new product of cable.

Other special characteristics: design and manufacuture according to customers'  special requirement

packing

company information

SYM HOIST & TOWER CRANE EQUIPMENT CO.LTD.located in Shenyang China is one of the biggest supplier and export of tower crane,luffing crane topless crane,passenger hoist along with the spare parts for them.With 21 year’s experience on tower crane rent installation and reconstruction，the company has more than 50 experienced mechanical and electrical engineer responsible for the installation guide,failure diagnosis,maintaince and reconstruction for the tower crane at the construction site.Having a long-time and good cooperative relationship with China’s most famous manufacturer of tower crane and passenger hoist like YONGMAO,SANYO,Sichuan SCM,Zoomlion GJJ,BAODA,etc.The company can offer you the best quality original tower crane and passenger hoist with most competitive price.

our certificate

our service

why choose SYM

FAQ

Q1<>: Are you a trading company or a factory?

A1<>: We are a trading company and have our own factory. We have both the price advantage of the factory and the thoughtful service of the trading company; and the advantage of taking responsibility.

Q2<>: Can you OEM production?

A2<>: Yes, we can customize the production according to the drawings.

Q3<>: How long is your delivery time?

A3<>: If the goods are in stock, usually 5-10 days. Or if the goods are not in stock, then 15-20 days, depending on the quantity.Always welcome you to visit China for ordering!

Q4<>: Do you test all your goods before delivery?

A4<>: Yes, we have 100% test before delivery.

Q5<>: Is it convenient to see visit your factory ?

A5<>: Yes,we welcome every customer to visit our company.

Q6<>: What is your steel material?

A6<>: Q345B,Q235B
