In the hydraulic system, the flow control valve mainly controls the flow rate through the valve by changing the flow passage area of the valve port, thereby realizing the adjustment and control of the movement speed (or rotation speed) of the actuator (hydraulic cylinder or hydraulic motor).
MODEL INSTRUCTION
| Name | Model examples | Specifications | Connection Type |
| (One-way) throttle valve | TY-MK6G1X/2 | 6/8/10/15/20/25/30 | Tube type |
| Two-way flow control valve | TY-2FRM6-3X/32 | 6/10/16 | Plate type |
TECHNICAL FEATURE
01.High-pressure series flow control valves are mainly used in industrial and engineering fields such as engineering machinery, sanitation machinery, indoor machinery and injection molding machine industry.
02.Compact structure and stable performance
03.High flow regulation accuracy and good uniformity
04.Good anti-blocking performance and large adjustment range
SPECIFICATION
| Model |
Maximum working pressure(MPa) |
Use flow range (L/min) |
| TY-MG/MK6/8/10/15/20/25/30 | 31.5 | 15~400 |
| TY-2FRM6 | 31.5 | 32 |
| TY-2FRM10/16 | 31.5 | 160 |
APPLICATION AREA
High-pressure series flow control valves are mainly used in industrial and engineering fields such as engineering machinery, sanitation machinery, indoor machinery and injection molding machine industry.
