Home > Industrial Equipment & Components > Valve > Ball Valve > Ty-SL10PA1-4X Hydraulic Directional Control Valve-Position Monitoring Electro-Hydraulic Reversing Valve
Ty-SL10PA1-4X Hydraulic Directional Control Valve-Position Monitoring Electro-Hydraulic Reversing Valve
US$ 15 - 55
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
MEDOX
Place of Origin:
China
Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN/HONGKONG
Delivery Detail:
3 days
Related Products
-
Hydraulic Electromagnetic Reversing Valve-Electro-Hydraulic Reversing ValveUS$ 15 - 55MOQ: 1 Piece -
Electro-Hydraulic Reversing Valve-Electromagnetic Reversing Valve-Tubular Check ValveUS$ 15 - 55MOQ: 1 Piece
-
Hydraulic Tubular Check Valve-Flow Control Valve-Cartridge ValveUS$ 15 - 55MOQ: 1 Piece
-
Tyzz Hydraulic Cartridge Check Valve-Pilot Operated Sequential ValveUS$ 15 - 55MOQ: 1 Piece
-
Hydraulic Cartridge Check Valve-Pilot Operated Position Monitoring Electromagnetic Cartridge ValveUS$ 15 - 55MOQ: 1 Piece
Brand Name
MEDOX
Place of Origin
China
Material
Stainless Steel
Application
General
Structure
Plug
Standard or Nonstandard
Standard
Pressure
High Pressure
Power
Hydraulic
Port Size
Shenzhen/HongKong
Media
Oil
Temperature of Media
Normal Temperature
The directional control valve mainly controls the oil passage in the hydraulic system to open or close or change the flow direction of the oil, thereby controlling the starting or stopping of the hydraulic actuator, changing the moving direction of the actuator, and meeting the requirements of different working conditions.
MODEL INSTRUCTION
| Name | Model examples | Specifications | Connection Type |
| Electromagnetic reversing valve | TY-4WE6E6X/G24NZ5L | 6/10 | Plate type |
| Electromagnetic reversing valve | TY-4WE6E6X/G24NZ5L/A12 | 6/10 | Plate type |
| Electro-hydraulic reversing valve | TY-H-4WEH16E6X/G24NZ5L | 10/16/25/32 | Plate type |
| Tubular check valve | TY-S6A1-1 | 6/8/10/15/20/25/30 | Tubular |
| Cartridge check valve | TY-M-SR10KE30-1X/ | 6/8/10/15/20/25/30 | Cartridge |
| Hydraulic check valve | TY-SL10PA1-4X/ | 6/10/20/32 | Plate type |
TECHNICAL FEATURE
01.Simple and compact structure, strong versatility
02.Small pressure lose
03.High pressure, high frequency commutation, smooth and no noise
SPECIFICATION
| Model | Maximum working pressure(MPa) | Use flow range (L/min)) |
| TY-WE6 | 35 | 80 |
| TY-WE10 | 31.5 | 120 |
| TY-WE6/A12 | 35 | 60 |
| TY-WE10/A12 | 31.5 | 100 |
| TY-WEH10/16/25/32 | 35 | 160~1100 |
| TY-S6/8/10/15/20/25/30 | 31.5 | 18~450 |
| TY-M-SR8/10/15/20/25/30 | 31.5 | 35~400 |
| TY-SL(V)6 | 31.5 | 60 |
| TY-SL(V)10/20/32 | 31.5 | 150~550 |
APPLICATION AREA
High-pressure series directional control valves are mainly used in industrial and engineering fields such as metallurgy, sanitation machinery, mining machinery and injection molding machines.
