Soft Package Cone Winding Machine Before Yarn Dying Using

Soft Package Cone Winding Machine Before Yarn Dying Using photo-1
Soft Package Cone Winding Machine Before Yarn Dying Using photo-2
Soft Package Cone Winding Machine Before Yarn Dying Using photo-3
Soft Package Cone Winding Machine Before Yarn Dying Using photo-4
Soft Package Cone Winding Machine Before Yarn Dying Using photo-5
US$ 1000 - 30000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
TANGSHI
Place of Origin:
China
Model Number:
TS008S
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI PORT
Delivery Detail:
20 days
Brand Name TANGSHI
Place of Origin China
Model Number TS008S
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 year
Weight 400KG/Section
Dimension(L*W*H) 2.2 x 1.25 x 1.58 meter/section
Production Capacity 300-1000 meter/min
Voltage 380V/3 phases
Certification CE
Application soft package cone winding before yarn dying
Condition New
Power(W) 0.09kw/spindle
Automatic Grade Semi-Automatic
Memory Capacity plc

TS008S Soft winding Machine

TS008S Soft winding machine

dying bobbin

TS008S Soft winding Machine

cheese bobbin winding machine

Soft winding machine


Machine Application:

TS008S High Speed Soft winding machine, it's mainly for the Yarn Dyeing preparing using, suit for winding like Cotton yarns, Spun Yarn, Sewing thread, Embroidery thread, DTY, Polyester yarns and etc, and it can take up with Conical Cone or Tube bobbins. It has the feature of High Efficiency and well take-up finished shape, can alleviate the intensity of labor for next processing work.


Technical parameters:



Bobbin type 6’(170mm)
Layout Double-side, can be 12-120 spindles
Power Supply Three phases 380-400V 50/60HZ
Driving Every spindle per motor
Power Consumption 0.09KW/spindle
Take-up package Tube Bobbin (0°) / Cone 4°20, 5°57, 9°15
Yarn tension  Every spindle with disc tensioner
Auto Stop Device Each spindle has yarn detector
Working speed 300-1000 Meter/min.
Cleaner device Every spindle has a Mechanical Knife yarn cleaner
Length counter Each spindle has length counter
Electronic Yarn Cleaner Optional installed
Air Splicer Optional installed
Blower cleaner Optional installed


Dimensions L 11500 x W 1050 x H 1550 mm (60 Spindles)


Product Tag: Soft winding machine,CHeese bobbin winding machine,soft package winder machine for yarn dyeing using

Product Tags: soft winding machine , cheese bobbin winding machine , soft cone winding machine , winding machine dying , dying yarn winding machine , soft package cone winding machine , high speed winding machine , cotton yarn winding machine
