Acrel 300286.SZ recharge onlinr LCD RS485 modbus rtu prepayment multi tariff kwh meter ADL100-EYNK/F

Name: Acrel 300286.SZ recharge onlinr LCD RS485 modbus rtu prepayment multi tariff kwh meter ADL100-EYNK/F
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Product Description

Parameters

Rated voltage		3*200/380V
Voltage reference frequency		50Hz
Voltage consumption		<4VA(Each phase)
Input current		1(6)A, 10(80)A
Starting current		Connet directly:0.004 Ib, Connect via CT:0.002In
Current consumption		<4VA
Accuracy		Class 0.5
Clock accuracy		≤0.5s/d
Active pulse	Pulse width	80±20ms
	Pulse constant	6400imp/kwh, 400imp/kwh
Communication	Interface	RS485
	Connection mode	Shielded twisted pair condutors
	Protocol	MODBUS-RTU
Dimensions(Length * Width* Height)		144mm88mm70mm
Maximum wiring ability(flexible cable)		25mm²
Temperature	Operature temperature	-25℃~55℃
	Storage temperature	-40℃~70℃
Relative		≤95%（No condensation）
Altitude		<2000m

Jiangsu Acrel Electrical Manufacturing Co.,LTD.: Contact nameRobin Wong; Phone86-188-60990280
