Halogen Lamp 50W Platform Boundary Light
Application:
Platform boundary light is mounted on the boundary of helicopter platform to provide light sign. Nose limeted line light provide light sign for helicopter in the front of platform. FWD limited position light provide the marker line of FWD limited position LZ platform.
Product characteristic:
1. The body use the good quality casting brass, pressure bearing 2MPa of protection Net, glass lampshade 1MPa.
2. Receed-type, flange is welde with warship hull, up-cover can open to replace the bulb.
3. Sealed body, it is well water proof.
4. Equip the special marine signal bulb.
5. According to the GJB534B-2009
6. Incoming wire can use cable connector or cable gland.
Drawing:
Specification:
Type | CXDJ-1 | CXDJ-2 | |
Voltage | AC220V/50Hz | ||
Power | 1*50w | ||
Lamp holder | G5.3 | ||
Illuminant | Halogen lamp | ||
Visibility | Over 1.5n.m. | ||
Cable outside diameter | 9-11 | ||
Protection class | IP56 | ||
Material | Cast brass | ||
Color | White | Red | |
Weight | 12.8KG( inclde the flange) | ||
With the aim of "to establish a close strategic partnership and develop together with customers",
we will work whole-heartedly to improve our products and service
BOCHI can provide CCS, ABS, DNV, GL, LR, RINA, BV, NK, KR, RS...etc.
We can satisfy all the customers requirments.
Factory:
If u have any enquiry or requirments pls contact me and I must make my reply asap.
