Help CenterTurbocharged 3 Phase 4 Wires Marine Diesel Generator Set
Related Products
-
Turbocharged AC Voltage Sound Proof Marine Diesel Generator SetUS$ 3,000 - 50,000MOQ: 1 Set -
Turbocharged Sound Proof Water-cooled Marine Diesel Generator SetUS$ 5,500 - 11,000MOQ: 1 Set
-
Turbocharged Electric Start Water Cooled Marine Diesel Generator SetUS$ 2,000 - 8,000MOQ: 1 Set
-
Marine Diesel 13 Hp Boat EngineUS$ 1,000 - 1,500MOQ: 1 Piece
-
Diesel Outboard Motor 4 StrokeUS$ 1,700 - 5,900MOQ: 1 Piece
Gensets Model |
BMMPPMGY100 |
BMMPPMGY100 |
BMMPPMGY120 |
BMMPPMGY120 |
|
Rated Capacity(KVA) |
100/125 |
100/125 |
120/150 |
120/150 |
|
| Engine | Diesel Model | YC6108ZLCB |
YC6A170C |
YC6A170C |
YC6M195C |
| Rated power/Speed(KW/r/min) | 112/1500 |
125/1500 |
125/1500 |
143/1500 |
|
| Type | Vertical,inline,water-cooled,4 stroke |
||||
| Intake way | Turbo-cooled&inter-cooled |
||||
| No. of Cylinder - bore*stroke | 6 - 108*132 |
6 - 108*132 |
6 - 108*132 |
6 - 120*145 |
|
| Starting type | Electric start |
||||
| Total displacement(L) | 7.252 |
7.252 |
7.252 |
9.839 |
|
| Min.fuel consumption g/(KW.h) | ≤195 |
≤189 |
|||
| Oil capacity(L) | 22 |
22 |
22 |
34 |
|
| Lw Noise limit | ≤98 |
||||
| Generator | Lan Generator Model | TZHW-100 |
TZHW-100 |
TZHW-120 |
TZHW-120 |
| Rated voltage | 400 |
400 |
400 |
400 |
|
| Current(A) | 181 |
181 |
216 |
216 |
|
| Regulator approach | AVR |
||||
| Freq.(Hz) | 50 |
50 |
50 |
50 |
|
| Power factor(CosΦ) | 0.8 lagging |
||||
| Phase | 3-phase |
||||
| Package | Net Weight(kg) | 1680 |
1730 |
1760 |
2600 |
| Packing size L*W*H(mm) | 2000*820*1300 |
2500*960*1500 |
|||
The main technical indexes
1.characteristic of voltage regulation
ratio of steady state voltage regulation ≤±2.5% ratio of transient state voltage regulation ≤±20-15%
steady time ≤1.5 ratio of voltage fluctuation ≤±1% voltage setting range of non-load 95-105%rated current
2.performance of governoring
ratio of steady governoring ≤5% ratio of transient governoring ≤±10%
steady time ≤5S ratio of rotating speed fluctuation ≤±0.5%
3.The generator set can overload 10% of the rated power for an hour after 12hours of rated power continuously .
4.Generator set can keep parallel running for a long time. The generator set can run steadily when the load changes at 20%-100% of rated power factor and can transform the load’s active power and reactive power steadily. The active power’s distribution degree can’t exceed 15% of the generator’s rated power, and the reactive power’s distribution degree can’t exceed 10% of the generator’s rated power
we can supply all kinds of marine diesel generator set.
We can supply all scopes of marine engine,from 10kw-3000kw.If you need engines,don't miss us.Please feel free to contact us.We can provide you best service and prices!
Equip China,Power World!
Verified Information
This information was Verified by Bureau Veritas and its Validity Period is 2012/07/11 --- 2013/07/10
The information below covers both the Gold Supplier and its related companies, which are defined according to china laws and regulations, and which will also be clearly displayed in the full report.
Production Capacity:
Product Line Name |
Production Line Capacity |
Actual Units Produced(Previous Year) |
Marine engine |
1,200 sets |
989 sets |
Export Market Distribution:
Market |
Revenue(Previous Year) |
Total Revenue (%) |
South America |
USD 50,000 |
0.39 |
Eastern Europe |
USD 2,110,000 |
16.36 |
Southeast Asia |
USD 3,200,000 |
24.81 |
Africa |
USD 72,000 |
0.56 |
Mid East |
USD 1,180,000 |
9.15 |
Eastern Asia |
USD 60,000 |
0.47 |
Western Europe |
USD 268,000 |
2.08 |
Domestic Market |
USD 5,960,000 |
46.20 |
Production Machinery:
Machine Name |
Brand & Model No. |
Quantity |
Number of Year(s) Used |
Condition |
Plate shearing machine |
QC11Y-6X3200 |
1 |
2.0 |
Acceptable |
Bending machine |
WC67Y-125/3200 |
1 |
2.0 |
Acceptable |
Rolling machine |
Self-made |
1 |
2.0 |
Acceptable |
Welding machine |
LGK-100 |
4 |
2.0 |
Acceptable |
Lathe |
C6136A |
1 |
2.5 |
Acceptable |
Planing machine |
B665 |
1 |
2.2 |
Acceptable |
Drilling machine |
Z32 |
2 |
2.0 |
Acceptable |
Crane |
10T |
2 |
3.0 |
Acceptable |
Testing Machinery:
Machine Name |
Brand & Model No. |
Quantity |
Number of Year(s) Used |
Condition |
Diesel generator set testing system |
Self-made |
1 |
0.5 |
Good |
Transformer |
TJA-500 |
2 |
3.0 |
Acceptable |
Water loader |
Self-made |
4 |
0.5 |
Good |
Cooling system |
Self-made |
3 |
3.0 |
Acceptable |
Production Flow:
Certificate:
Certified Picture |
Certification Name |
Certified By |
Product Name & Model No. |
Available Date---Expired Date |
|
ISO9001:2008 |
QAC; CNAS |
Manufacture of 30-1500KW Diesel Generator Sets |
2011/07/25 --- 2014/07/24 |
|
GB/T28001-2001 |
QAC; CNAS |
Chongqing bochi machinery co., ltd. is engaged in design, produce, sell and after sell services of eninge and the relevant occupation health & safety management activities. |
2009/10/20 --- 2012/10/19 |
