Product Description
Air flow volumns of the industrial water air cooler of 30,000m³/h which helps to create an environment with comfortable temperature and humidity.
Item No. |
YiHoo-30 |
Voltage / Frequency |
220V/50Hz |
Airflow |
30000(m³/h) |
Fan Type |
Axial |
Fan Speed Stages |
12 |
Power |
3KW |
Dimensions |
1260x1260x1200mm |
Net Weight |
85kg |
Water Storage Capacity |
50L |
Evaporation Capacity |
40(L/H) |
Applicable Space |
200㎡ |
Materials |
Tough and Rigid PP |
Voltage / Frequency |
220V/50Hz (customizable) |
Water Cooling System inside the Water Air Cooler
The water air cooler uses a fan to draw in the hot air, and passes over water-moistened pads, the water-moistened cooling pads immediately cools the air, then the evaporative cooler releases this cool moisturized air into the space.
Great Cooling Effect
The air coolers can help to cool the air temperature down by 5~10 centigrade.
| Multifunction LED Touch Screen Control Panel | High Quality Water Air Cooler Accessories |
| Can be customized in multiple languages. | The wate air cooler parts and accessories shipped along with the air coolers |
| Water Pump | Water Outlet | Air Cooler Motor | Fan Blade |
| Double filtration water pump, it filters the impurities for smoother water flow | outlets automatically, cleans the water tank for better air quality | Fully copper motor, quiet and durable | High airflow, strong airvent at a long distance |
Air Cooler Options
| Upward Airvent Air Cooler | Downward Airvent Air Cooler | Side Airvent Air Cooler |
| Single Airvent | Double Airvent | 4 Airvent | 8 All-Around Airvent |
Size Chart of This Design
Item No. |
YiHoo-18 |
YiHoo-25 |
YiHoo-30 |
YiHoo-P18 |
YiHoo-120 |
Voltage / Frequency |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
Airflow |
18000(m³/h) |
25000(m³/h) |
30000(m³/h) |
180000(m³/h) |
12000(m³/h) / 7,000CFM |
Fan Type |
Axial |
Axial |
Axial |
Axial |
Axial |
Fan Speed Stages |
12 |
12 |
12 |
12 |
12 |
Power |
1.1KW |
1.5KW |
3KW |
1.1KW |
0.29KW |
Dimensions |
1100x1100x940mm |
1150x1150x1160mm |
1260x1260x1200mm |
1100x1100x1950mm |
870x 480x 1460mm |
Net Weight |
60kg |
80kg |
85kg |
60kg |
43kg |
Water Storage Capacity |
30L |
40L |
50L |
200L |
120L |
Evaporation Capacity |
25(L/H) |
35(L/H) |
40(L/H) |
25(L/H) |
15(L/H) |
Applicable Space |
100㎡ |
150㎡ |
200㎡ |
100㎡ |
100 to 120㎡ |
Materials |
Tough and Rigid PP |
Tough and Rigid PP |
Tough and Rigid PP |
Tough and Rigid PP |
Tough and Rigid PP |
Voltage / Frequency |
220V/50Hz (customizable)
|
220V/50Hz (customizable)
|
220V/50Hz (customizable)
|
220V/50Hz (customizable)
|
220V/50Hz (customizable) |
After Sales Service
One Year Warranty, Lifetime Aftersale Service
We offer 1 year warranty on the motors and the entire fan, and we will provide free spare parts for any defective models within the warranty period.
Company Introduction
MINXIN INDUSTRIAL is well known for its most complete production line for industrial exhaust fans, evaporative air conditioners, and mobile air coolers.
Our Services & Strength
Minxin Industrial was founded in 2015, since then Minxin has been specialized in manufacturing industrial exhaust fans and evaporative air coolers of all sizes, such as:
1. Minxin Belt drive ventilating exhaust fans
2. Minxin Direct drive ventilating exhaust fans
3. Yihoo Water-cooling evaporative air conditioner
4. Yihoo Mobile evaporative air cooler
Our Production Lines
Supporting 120 employees, our 20,000 square meter factory is top-notch, Minxin Industrial equipped itself with all the production equipment processes in house for better control of the quality and delivery time:
1. Steel coil sliding and cutting line, steel pipe cutting line
2. Aluminum Die Cast Tooling & Casting
3. Plastic Molding & Injection workshop
4. Metal Stamping & Laser Cutting
5. Motor Copper Coil Winding Line
6. Motor Assembly Workshop
7. Exhaust Fan Assembly Workshop
8. Water Air Cooler Assembly Workshop
| Steel coil sliding and cutting line, steel pipe cutting line | Aluminum Die Cast Tooling & Casting | Plastic Molding & Injection workshop |
| Motor Copper Coil Winding Line | Motor Assembly Workshop | Stamping Workshop |
| Wire Guard Welding | Fan Parts CNC Machining | Laser Cutting |
