Lab Test Equipment Salt Corrosion Fog Spray Test Chamber

Guangdong Yuanyao Test Equipment Co., Ltd
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber thumbnail-1
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber thumbnail-2
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber thumbnail-3
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber thumbnail-4
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber thumbnail-5
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber photo-1
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber photo-2
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber photo-3
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber photo-4
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber photo-5
US$ 1500 - 3000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Yuanyao
Place of Origin:
China
Model Number:
YSST-270
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Yuanyao
Place of Origin China
Model Number YSST-270
After-sales Service Provided Engineers available to service machinery overseas
Condition New


Lab Test Equipment Salt Corrosion Fog Spray Test Chamber


Introduction&Application:

Salt corrosion test equipment, Brine salt spray erode tester, Salt corrosion test equipment, Salt fog

test chamber use salt fog corrosion way to test the reliability of materials and protective coating to resist

salt fog corrosion. It is widely applied to components and parts, electronic components, metal materials

protective layer and other industrial products, etc.
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber


Feature:

1 Entire PP&PVC solid mechanical structure, resistance to hydrochloric acid, heat resistance and never aging, suitable for salt fog copper acetate, etc.

2 Patent nozzle and conical diffusion device makes the fall fog rapidly and evenly. With manual level automatic control mode, the biggest setting time can reach 9990 hours.

3 Have automatic demist device, can clear observe tested products after the experience is finished.

4 Three complete temperature control systems(Saturated air temperature, the temperature in the cabinet, the test liquid temperature) ensure the consistency and standards of the test.

5 Meet international test standards.

6 Customization is available & welcomed.
Lab Test Equipment Salt Corrosion Fog Spray Test Chamber


Technicial Parameters

Specification
ModelYSST-108YSST-270YSST-600
Internal Dim.WHD(mm)600*400*450900*500*6001200*500*1000
 External Dim.WHD(mm)1250*1050*9101550*1210*10601900*1400*1300
Temp. Range ChamberRoom temp.-- 50ºC,±0.5ºC
AirRoom temp.--63ºC,±0.5ºC
 SaltRoom temp.--50ºC,±0.5ºC
Saturated Air Pressure(Kg/m)0.8--2.0
Spray Volume(m/80cm/hr)0.5--3.0
PHSalt6.5--7.2
Cu(CH COOH)3.0--3.2
Exter,/Inter.MaterialP.V.C & P.P
SystemsSalt Spray VeicleAir+acid(base)liquid
 Heating SUS#304 & #316stainless steel heater+taflon
ControllerHydrometer,salinomerer,fog collector,glassbar
Other ComponentsDigital electronic control+S.S.R
Savety DevicesOverheating prevention circult-breaker,dehydration and
overheating prevention mechanism,breakdown indicator light
Power Source[K.W]AC 1Ψ 220V  60/50Hz
1.11.53.5
Comply with ASTM B-117, B-287,B-380,JIS D-0201, D-0205, H-8681, Z-2371, K-5400 ^^

Lab Test Equipment Salt Corrosion Fog Spray Test Chamber
Package & Delivery

Package: Wooden cases, meet the international standard.
Delivery: In 15-20 working days.
Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)


Product detail:
Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)



Technical parameters: See the label.

Specification
ModelYSST-108YSST-270YSST-600
Internal Dim.WHD(mm)600*400*450900*500*6001200*500*800
 External Dim.WHD(mm)1070*580*10301380*800*11501700*950*1210
Temp. Range ChamberRoom temp.-- 50ºC,±0.5ºC
AirRoom temp.--63ºC,±0.5ºC
 SaltRoom temp.--50ºC,±0.5ºC
Saturated Air Pressure(Kg/m)0.8--2.0
Spray Volume(m/80cm/hr)0.5--3.0
PHSalt6.5--7.2
Cu(CH COOH)3.0--3.2
Exter,/Inter.MaterialP.V.C & P.P
SystemsSalt Spray VeicleAir+acid(base)liquid
 Heating SUS#304 & #316stainless steel heater+taflon
ControllerHydrometer,salinomerer,fog collector,glassbar
Other ComponentsDigital electronic control+S.S.R
Savety DevicesOverheating prevention circult-breaker,dehydration and
overheating prevention mechanism,breakdown indicator light
Power Source[K.W]AC 1Ψ 220V  60/50Hz
1.11.53.5
Comply with ASTM B-117, B-287,B-380,JIS D-0201, D-0205, H-8681, Z-2371, K-5400^^



Except Reliable environment test cabinet, Guangdong Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)


Company profile
Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)

Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)
Simulated Environmental Salt Spray Corrosion Test Machine (YSST-108)
If you are interested in the items, please let us know. We will be happy to give you the details.
