Help CenterShengHua Power Amplifier
Negotiable
MOQ: 30 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
ALD
Place of Origin:
China
Model Number:
PA series
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
ALD
Place of Origin
China
Model Number
PA series
| Models | PA4600 | PA4800 | ||
| Rated power(1KHz,THD+N=0.1%) | 8ohm stereo | 4x600 | 4x800W | |
| 4ohm stereo | 4x900W | 4x1200W | ||
| 8ohm bridge | 2x1800W | 2x2400W | ||
| Frequency response | 20Hz-20kHz(±0.3dB) | |||
| SN Ratio | 20Hz-20kHz | ≧98dB | ≧105dB | |
| Total Harmonic Distortion(THD+N) | 20Hz-20kHz.Half Power | ≦0.1% | ≦0.1% | |
| Slew Rate | Rated Power into 8ohm | 100V/µs | 100V/µs | |
| Damping coefficient | 8ohm、1f=1kHz | 600:1 | 800:1 | |
| Input Sensitivity | Rated Power into 8ohm | 0.775V | 0.775V | |
| Input Cmrr | 8ohm | ≧62db | ≧62db | |
| Inpur Impedance | Balanced/unbalanced | 10K ohm/ Unbalanced,20K ohm/ Balanced | ||
| Tour class protection | PROTECTION OF SHORT CIRUIT, OPEN CIRCUIT, OVERHEAT, | |||
| OVER LOAD, DC, SUPER SONIC FREQUENCE | ||||
| Class | H | |||
| Power Supply | 220V/50Hz | |||
| Outer packing | MM | 655*585*158 | ||
| Weight | KG | 25 | 30 | |
