Environmental High Low Temperature Humidity Stability Climatic Test Chamber
high-low temperature Environmental test cha
DESK TOP TEMPERATURE HUMIDITY TEST CHAMBER
Desk Top Temperature Humidity Test Chamber offer flexibility, uniformity, and control accuracy required for cost effective testing for a variety of products.
Application
Desk Top Temperature Humidity Test Chamber is applied to test various types of materials for their tolerances of heat, cold, dry, humidity, and applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automotive, aerospace, chemical, electronics and materials and substance testing.
Featuers
1. Delicate touch and excellent user experience;
2. Unique and compact design, topgrade appearance, stable performance and easy operation;
3. Can simulate a wide range of temperature and humidity environments;
4. Capable of testing large components, assemblies, and finished products;
5. Customized sizes and configurations avaible;
6. One year warranty
7.Visually attractive with large windows
8.Space-saving and Compact with optimized test chamber volumes
9.Powerful, suitable for a broad range of applications involving temperature and relative humidity

| Technical Parameter Environmental Temperature and Humidity Chamber | ||||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | ||||
| Model | KMH-R series | KMH-L series | KMH-S series | |
| 36R | 36L | 36S | ||
| Temp. range | -20ºC~150ºC | -40 ºC~+150ºC | -60ºC~+150ºC | |
| Interior sizel | W(mm) | 300 | 300 | 300 |
| H(mm) | 400 | 400 | 400 | |
| D(mm) | 300 | 300 | 300 | |
| Exterior size | W(mm) | 460 | 460 | 460 |
| H(mm) | 780 | 780 | 780 | |
| D(mm) | 1020 | 1020 | 1020 | |
| Power(KW) | 4.5 | 4.5 | 4.5 | |
| Weight(KG) | 150 | 150 | 150 | |
| Humidity uniformity | ±3.0%R.H | ±3.0%R.H | ±3.0%R.H | |
| Heat up time | -20ºC~+100ºC,within 35 min | -40ºC~+100ºC, within 45 min | -60ºC~+100ºC,within85 min | |
| Pull down time | +20ºC~-20ºC, within 45 min | +20ºC~-40ºC , within 60 min | +20ºC~-60ºC,within 80 min | |
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | |||
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, | |||
| Over temp. protect, over load protect of blower, dry heat protection | ||||
| Control System | Balanced Temperature & Humidity Control System | |||
| Refrigeration system | Air Cooled | |||
| Hermetic compressor,Single stage refrigeration system | ||||
| CFC-Free refrigerant(HFC-507/HFC-23) | ||||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | |||
| Operation model :Program or fix point running | ||||
| Memory capacity :120programs,1200steps, | ||||
| All repeat 999 cycles, part repeat 99 cycles | ||||
| Humidity Range | 20~98%R.H | |||
| Temp. constancy | ±0.5ºC | |||
| Humidity constancy | ±2.5%R.H | |||
| Temp. uniformity | ±2.0ºC | |||
| Interior material | Stainless Steel Plate(SUS 304) | |||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |||
| Ambient Temp. | +5ºC~+35ºC | |||
| Wiring method | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | |||



FAQ:
1. Are your company a trading one or a factory?
Factory ,13years focusing on test instruments field,3 years exporting experience.Our factory is in Dongguan, Guangdong, China
2. After an order is placed, when to deliver?
Usually about 15 working days, if we have finished products, we can arrange delivery within 3 working days.
Please note that our production lead time depends on the specific project and the number of projects.
3. What about the warranty with after - sales services?
12 months warranty.
After the warranty, the professional after-sales service team will provide comprehensive technical support to help customers solve problems encountered when using our products, and promptly handle customer problems and complaints.
4. What about the services and product' quality?
Service: ,Design service,Buyer lable service.
Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party calibration institutions before shipping and delivery goods.
