Home > Products > Tensile testing machine > for tensile test digital display 30/50/100kn geotextile tearing force tester with good guarantee
for tensile test digital display 30/50/100kn geotextile tearing force tester with good guarantee
- Guangzhou Shenzhen or decided by customer
- T/T Credit Card
You May Like
-
For compression test Tensile Machine with good price
-
For textile test belt tension testing machine with 1 year guarantee
-
maximum force universal tensile testing machine taiwan with 1 year guarantee
-
precision universal testing machine utm with good price
-
For plastic test universal tensile testing machine with high quality
-
Professional universal testing machine price with 1 year guarantee
Product Details
| Brand Name | Hongjin | Place of Origin | China | |
| Model Number | HY-UT-5PC | Power | Electronic |
Wooden package,Non-fumigation
Product Description
5kn tensile testing machine(PC type)
The main purpose:
Mainly used for testing of metal and non-metal materials, such as: rubber, plastic, wire and cable,textile, fiber optic cable, safety belt, leather belt composite, plastic profile, waterproof coil, steel pipe, copper, profile, spring steel.
Test Funcation:Stretching, compression, bending, shearing, peeling, tearing, two-point extension of bearing steel, stainless steel (and other high-hardness steel), castings, steel plates, steel strips, non-ferrous metal wires, etc. A variety of experiments.
| Maximum load | 500kgf |
| Accuracy level | Level 0.5 |
| Effective force range | 0.4% to 100% (0.5 level) |
| Force measurement accuracy | Within ±0.5% of the indicated value |
| Test machine resolution | he maximum load is 1/300000, the internal and external are not divided, and the resolution is unchanged. |
| Load cell | Basic configuration: pull and pressure sensor (maximum load)Extended configuration: multiple sensors can be added |
| Effective test width | 400mm (can be widened according to customer requirements) |
| Effective stretching space | 800mm (can be increased according to customer requirements) |
| Test speed range | 0.1~500mm/min |
| Displacement measurement accuracy | Within ±0.5% of the indicated value |
| Deformation measurement accuracy | Within ±0.5% of the indicated value (large deformation or small deformation can be selected according to customer requirements) |
| Test bench safety device | Electronic limit protection |
| Test bench lifting device | Fast/slow speed automatic control, can be jogged Manual or automatic selection, automatic or manual return the initialposition of the test at the highest speed after the test is over |
| Test bench return function | Manual or automatic selection, automatic or return to the position of the test at the highest speed the test is over |
| Overload protection | Over 10% of maximum load, automatic machine protection |
| Fixture configuration | Set of stretching fixtures |
| Host size | 1200*530*1800mm (length * width * height) |
| power system | Servo motor high precision ball scre |
| power supply | 220V/50HZ |
| power | 0.75KW (standard power motors are standard according to different force requirements) |
| Host weight | (about) 100 Kg |
multiple choice
click picture
touch control type |
Double column type(10kn-200kn for choice)
|
Hydraulic type |
Packaging & Shipping
About us
1.What's your MOQ?
At present we haven't strict policy for this, so welcome orders with any quantity.
2. Are you a factory or trade company?
We are a manufacturer located in Dongguan. You will be welcomed to visit our factory or we also can share our factory vedio for you at any time.
3. We are not professional for operation and installation of your machine?
While it is not a stumbling block, our machine is easy to operate, no need to professional training, and the instruction manual and video sent to you are enough. What's more, we have professional engineers and they can solve all questions.
4. How about packaging? If machine damaged, what should I do ?
Usually machine is packed with wooden case and standard export carton, plywood carton or as your requirement. Damage haven't happened before, if happen, we will arrange replacement.
5. We haven't do business before, how can I trust your company and machine?
We are a factory with more than 13 years and without amy complaints on Alibaba. and our machine have exported to many countries and have a good feedback.
6. If I want to visit your factory, is the traffic convenient ?
Our company traffic is very convenient, it is only 10 minutes by car or taxi from our city light rail to our company, we also can arrange the shuttle bus for you to our factory.
7. Does your product have CE certification ?
Yes, we not only have the CE certification,but also have the FCC,ISO,etc.
Company Profile
Hongjing Inspection Instrument Co., Ltd. is a high-tech enterprise which specializes in producing, developing and simulating various kinds of environmental testing equipment, mechanical testing equipment, luggage testing equipment, electronic and electrical testing equipment, wire and cable testing equipment and large-scale non-standard testing equipment design and automatic control.
