For compression test testing machine manufacturer customize
USD $3,500 - $11,000
/ Set
1 Set(Min.Order)
- 5 Set / Sets per Month
- Shenzhen Guangzhou or decided by customer
- T/T Credit Card
You May Like
-
for test high tensile bolts and nuts grade WDW-100 with CE certificate
-
For school steel tensile test with great price
-
For laboratory test 100ton Universal Testing Machine with high quality
-
For lab test Electronic compression testing machine with low price
-
Easy to control Test Equipment with cheap price
-
FCC certification tensile testing machine price india with 1 year guarantee
Product Details
| Brand Name | Hongjin | Place of Origin | China | |
| Model Number | HY-UT-50PC | Power | Electronic | |
Wooden package,Non-fumigation
Product Description
Tensile testing machine
Main Uses
It is mainly suitable for testing of metal and nonmetallic materials, such as rubber, plastic, wire and cable, optic fiber cable, safety belt, belt, leather composite belt, plastic section, waterproof roll, steel pipe, copper,sectional material, spring steel, bearing steel, stainless steel (and its high hardness steel), castings, steel plate and steel.
Test items
Extrude, compression, bending, shearing, stripping, tearing, two-point extension (with additional extensometer) and so on.
Extrude, compression, bending, shearing, stripping, tearing, two-point extension (with additional extensometer) and so on.
Universal Tensile Tester Performance parameter indicator
| Maximum load | 50KN(Selection of sensors with different specifications to achieve different accuracy) |
| Accuracy grade | 0.5 class |
| Effective force measurement range | 0.4%~100%(0.5 class) |
| Force measurement precision | Within±0.5% |
| Test machine resolution | Maximum load 1/300000,resolution invariant |
| Trans cell | Basic configuration: pull and pressure sensor (maximum load). Extended configuration: multiple sensors can be added |
| Effective test width | 400mm(can be widened according to customer requirements) |
| Effective stretch space | 800mm(can be higher by customer requirements) |
| Displacement measurement | Within±0.5% |
| accuracy | |
| Test speed range | 0.01~500mm/min |
| Deformation measurement accuracy | Within±0.5% ((large deformation or small deformation can be selected according to customer requirements) |
| Overload protection | More than 10% of the maximum load, automatic machine protection |
| Fixture configuration | A set of tensile fixture ,Shearing Accessories |
| Mainframe size | 1200*530*1800mm(long * width * high) |
| Power supply | 220V/50HZ, |
| Power | 0.75KW(according to the different force demand, standard different power motors) |
| Packed weight | 300Kg(include all accessories) |
Testing platform
The microcomputer hardware platform can accurately collect and process data in real time. The interface of measurement and control is gentle, intuitive, clear and clear, and easy to operate.
Universal Testing Machine Equipment Function
1.Automatic zeroing
2.Auto return
3.Automatic disk saving
4.The testing process, measurement, display and analysis are all finished by microcomputer
5.The data and curves are displayed dynamically with the experimental process.
6. Experimental results can be re analyzed with arbitrary access.
7.After the test is completed, the force and deformation data of the test curve can be found at point by point. 8.Program control and mechanical dual protection function;
9.Overload protection function;
10.Emergency shutdown function;
11.The tensile, compression, bending, shearing, adhesion, stripping and tear tests of the material can be carried out.
