Home > Instruments & Meters > Test Instrument > Test Machine > Hot Selling Wet Leakage Testing Equipment/Wet Leakage Current Testing Machine/Solar Panel Testing Machine
Hot Selling Wet Leakage Testing Equipment/Wet Leakage Current Testing Machine/Solar Panel Testing Machine
US$ 5,688.62 - 6,287.42
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HOTOTECH
Place of Origin:
China
Model Number:
HTPV-07B
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Panel Salt Spray Tester/Salt Mist Aging Testing Machine / Solar Panel Testing Machine for IEC61730 TestingUS$ 8,000 - 20,000MOQ: 1 Set -
Photovoltaic Module Breach Testing Machine/Solar Module Testing Equipment/Solar Panel Testing Apparatus for IEC 61730 StndardUS$ 6,287 - 7,784MOQ: 1 Set
-
PV Module Damp Heat Testing Machine/constant Temperature and Humidity Testing Chamber/evnironment ChamberUS$ 26,946 - 32,934MOQ: 1 Set
-
PV Module Damp Heat Tester/Solar Panel Damp Heat Testing Machine / Constant Temperature and Humidty Environment ChamberUS$ 26,470 - 32,934MOQ: 1 Set
-
Solar Panel Ice Ball Impact Testing Machine/Clash Testing Machine/Solar Panel Testing Machine With IEC61215-2:2016 StandardUS$ 8,000 - 22,000MOQ: 1 Set
Brand Name
HOTOTECH
Place of Origin
China
Model Number
HTPV-07B
Power
Electronic
Company logo
Product Description
Hot selling Wet leakage testing equipment/Wet leakage current testing machine/Solar panel testing machine
Standard
It's conform IEC61215-2:2016 testing standard
Purpose
It's to evaluate the insulation of the module under wet operating conditions and verify that moisture froom rain, fog , dew or melted snow does not enter the active parts of the module circuitry, where it might cause corrosion, a ground fault or a safety hazard
The mian technical specifications
| Product Name | Hot selling wet leakage testing equipment/wet leakage current testing machine/solar panel testing machine |
| Testing standard | IEC61215-2:2016 |
| Test tank size | 2100*1000*250mm (w*D*H) , thickness 15mm |
| Test tank material | plexiglass |
| Temperature control | water constant temperature system researched and development by HOTOTECH, temperature 22±℃ |
| Insulation output voltage | 0-5000V (adjustable) |
| Leakage current he maximum limit value | 5mA |
| Output speed rate | 500V/S |
| Isulation resistance test range | 1MΩ~999MΩ |
| Leakage current test range | 0.001~5.000mA (DC) |
| Electricity | 220V 50HZ |
