Solar panel ultraviolet pretreatment testerPV Module UV Aging Testing machineSolar panel testing machine with IEC61215
Standard
UV preconditioning testing chamber satisfy IEC61215 , IEC61646 ,IEC61345 standard etc
Purpose
Main specific PV module when expose to the ultraviolet irradiating environment,to check the
resistance ultraviolet irradiating ability test ,and evaluate save polymer material and protect layer etc material resistance ultraviolet irradiating performance . Main use PV industry and solar industry
necessary test equipment , use test PV component , main is monocrystalline silicon components ,the ground uses crystalline silicon photovolatic modules ,the ground sues thin film photovoltaic modules and a series of photovoltaic modules for UV accelerated weathering test can represent the damage
produced by the sun .
The Main Technical Specifications
| Product Name | Solar panel ultraviolet pretreatment testerPV Module UV Aging Testing machineSolar panel testing machine with IEC61215 |
| Testing standard | IEC 61215-2:2016 testing |
| Testing samples | Solar panels |
| Testing samples size | 2m×1m ( customized) |
| Interior size approx | 1150×1060×2430mm (D×W×H) |
| External | 1950×1510×2980mm (D×W×H) |
| Temperature range | RT+10℃~80℃ |
| Humidity range | 90~98%R·H |
| Humidity uniformity | ±2% |
| Temperature uniformity | ±2℃ |
| wavelength accurate | ≤±15% |
| Irradiation uniformity | ≤±15% |
| Temperature fluctuation | ±0.5℃ |
| Humidity fluctuation | ±2%. |
| Control temperature method | PID control temperature method |
| Effective ultraviolet area | 1580×808mm or 1956×992mm etc |
| Ultraviolet fluctuation | UV-A the wavelength range 280-385nm;UV-B wavelength range 280-320nm |
| Test time | 0~999H adjust |
| Black board temperature | 40℃~65℃ |
| Electricity | 380V 50 HZ |
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
