Solar Panel Load Tensile Strength Testing Machine/compression Testing Equipment With IEC61215-2:2016 Standard
US$ 40,579.71 - 46,376.81
/ Set
1 Set(Min. Order)
- shenzhen
- T/T Credit Card
You May Like
-
PV Solar Panel Surface Area Testing 11 Locations Impact Strength Testing Machine With IEC61215-2:2016 Testing Standard
-
Customized Walk-in High Low Temperature Environment Testing Machine/temperature and Humidity Chamber/solar Panel Testing Machine
-
Solar Panel Programmable Constant Temperature and Humidity Environment Testing Machine
-
Customization Industrial High Low Temperature Humidity Cycling Testing Chamber/ Testing Machine for pv Module
-
Real-time Curve Display High-Low Temperature Test Chamber With PV Module Testing
-
PV Module/Solar Panel UV Preconditioning System Test Chamber/Testing Machine With IEC61215-2:2016 Standard
Product Details
| Brand Name | HOTOTECH | Place of Origin | Guangdong, China | |
| Model Number | HTPV-08-2 |
Product Description
Company logo
Product Description
Solar panel Load tensile strength testing machine/compression testing equipment with IEC61215-2:2016 standard
Standard
It's conform IEC61215, IEC61646,IEC62782 etc standard
Purpose
This testing is to determine the ability of the module to withstand wind, snow, static or ice loads
The Main technical specifications
| Product Name | Solar panel load tensile strength testing machine/compression testing equipment with IEC61215-2:2016 standard |
| Testing standard | IEC61215,IEC61646,IEC 62782 etc testing standard |
| Testing sample | Solar panel |
| Testing sample dimension | 2000×1000mm (can customized) |
| Testing positive load | 5400 Pa |
| Testing reverse load | 2400 Pa |
| Pneumatic and force value feedback ways | low friction force cylinder, tensile pressure |
| Raw material | Aluminum profile structure |
| Current continuity system | DC Power, DC 150V/2A , real-time monitor module inner current continuity |
| Cyliner | 4 groups , intotal 8 pieces, single the maximum output >200kg, telescopic stroke 125mm |
| Sucker | 8 groups, in total 32 pieces , diameter 120mm |
| Sucker (with cylinder) space horizontal and vertical | ≤200mm |
| Sucker angle | can rotation angle ≥15° |
| Control system | Computer control |
| Interface display | Computer with real-time curve display |
| Additional function | Fault alarm function |
| Electricity | 220V 50HZ |
Test procedure
Products images show
Exhibition
Clients visit photos
Package show
Nameplate
