IEC61215 Solar Panel Hail Impigement Testing Machine pv Module Anti-hail Impact Testing Machine
US$ 200 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HOTOTECH
Place of Origin:
Guangdong, China
Model Number:
HTPV-09, HTPV-09
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen YanTian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Detection Cord Anchorage Torsion Ability Testing Equipment/Solar Panel Testing MachineUS$ 200 - 900MOQ: 1 Set -
Solar Panel Environment Climate Chamber Thermal Cycling/Humidity -freeze Testing Machine (environment Chamber) IEC61215 UL1703US$ 300 - 3,000MOQ: 1 Set
-
Class AAA Steady-state Sun Simulator (included the IV Curve Tester) Class AAA Sunlight Simulates the Environment ChamberIEC61215US$ 300 - 2,000MOQ: 1 Set
-
IEC61215 STC and NMOT Measurement Testing MachineUS$ 2,300 - 2,300MOQ: 1 Set
-
IEC61215 IEC61646 Solar Panel UV Preconditioning Testing Machine / Testing EquipmentUS$ 600 - 10,000MOQ: 1 Set
Brand Name
HOTOTECH
Place of Origin
Guangdong, China
Model Number
HTPV-09, HTPV-09
Power
Electronic
Product Description
Model:HTPV-09A
Name:Hail Impact Testing Machine
Solar panel hail impigement testing machine
pv module anti-hail impact test machine
Standard:According to IEC61215,IEC61646,UL1703 standard requirement
Purpose:to verify that the module is capable of withstanding the impact of hailstones
Technical specifications:
| launch device | Moving locating device | ||
| Power source | air compressor | X shaft move distance | approx 2100mm |
| Air pressure | 6-8bar | Y shaft move distance | approx 1000mm |
| Ice ball single filled | manual | Locating accurate | ≤1mm |
| The barrel length | approx 940mm | Impact area | 2000×1000mm |
| The barrel | can change | Guide ways | high quality import guide rail |
| Locating control ways | PC control and automatic locating | ||
| Driving ways | import servo motor + synchronous wheel | ||
| Ice ball speed | Test velocity system | ||
| diameter 25 mm | 23.0m/s ±5% | Test speed sensor | high accurate infrared test speed sensor |
| diameter 25 mm | 27.2m/s ±5% | accurate | ±5% |
| accurate | 30.7m/s ±5% | Speed catch range | 0~50 m/s |
| ice mould | |||
| material | does not expand easily | ||
| Inner cavity diameter | 25mm<1%;35mm<1%;45mm<1% | ||
| ice ball diameter | 25mm<5%;35mm<5%;45mm<5% | ||
| ice ball weight | 7.53g<5%;20.7g<5%;43.9g<5% | ||
| Refrigerator | -10℃ | ||
testing machine ima
about us
Our Services
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
