HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp

HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-1
HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-2
HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-3
HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-4
HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-5
HT206D Digital Clamp Meter True Rms Pinza Amperimetrica Multimeter Clamp photo-6
US$ 21 - 22.17 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HOTOTECH
Place of Origin:
Guangdong, China
Model Number:
HT206D
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name HOTOTECH
Place of Origin Guangdong, China
Model Number HT206D
Weight Approx.260g
Operating Temperature normal temperature
Dimensions 193mm*73mm*34mm
Measuring Inductance Range NO
Measuring Capacitance Range 10nF-100mF
Measuring Resistance Range 6KΩ/60KΩ
Measuring Voltage Range 600mV/6V/60V/600V/600V
Measuring Current Range 6A/60A/600A
Display Type Digital Only



HT206D

True-RMS AC Clamp Meter





Introduction of functions

1. Intelligent anti-burning and overload protection
Full - range intelligent overload protection to prevent damage to license issuing instruments during measurement.
2. Automatic measuring range
The matching of engineering switch keys and dial plate effectively reduces the wear of dial plate and prolongs the service life of instrument.
The dial is not required to switch the measuring range and the resolving range, thus improving the measuring accuracy.
3. High - definition display screen with clear handwriting, clear display and convenient use in dark places
4. NCV non-contact measurement
NCV gear automatically detects the voltage intensity when the non-contact voltage sensing area is close to the circuit.



specifications

specifications

range

accuracy

HT206A

DC Voltage

600V

±(0.5%+3)



600mV/6V/60V/600V/600V



AC Voltage

600V

±(1.0%+5)



6V/60V/600V/600V



AC Current

6A/60A/600A

±(2.5%+5)

Resistance

6KΩ/60KΩ

±(1.0%+3)



600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ



Capacitance

10nF/100nF/1uF/10uF/100uF/1mF/10mF



Frequency

10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz



Duty

1%~99%



Temperature(℃/°F)

-40~1000



-40°F~1832°F



Counters

6000 counters

Auto/manual range

Manual

Continuity                      (sound and light alarm)

Diode test



Data hold

NCV                           (sound and light alarm)



Backlight

Flashlight

Low battery indication

Auto power off

True RMS



LPF



Max/MIN

LowZ



Power

2*AAA(1.5V)batteries

Weight

Appro*.260g

Size

193mm*73mm*34mm

Safety rating

EN61010-1,-2-030 EN61010-2-033,EN61326-1 CAT III 600V
