Walk-in Climate Test Chamber for Low High Temperature And Humidity
Introduction:
Walk-in rooms are perfect for any product testing that requires a higher volume than standard units.Our walk-in rooms feature fast temperature change rates, high humidity and explosion resistant applications.
Features:
• This series product use polyurethane panel,the inner surface is made of stainless steel,the surface of the shell is made of color steel.It has firm structure and easy installing,with a elegant appearance and novel design.
• We adopt import fittings as our main control fittings to ensure oven quality.
Use the newest cooling conrol model in the international , it can adjusted the cooling power of the compressor reach to 0%-100% automatically to realize low energy consumption run of the machine.
• Configured with Multi-panel sliding doors and inboard type Illumination,, it provides good observation for the specimen's working.
• Size and performance can be customized by customers.
• This system has simple operation and convenient to install,training and Maintenan.
Parameters:
| purpose | Non-standard testing instrument(It is applicatable for the testing of electronics,household appliances, automotive electronics and materials to prosess whole machine or sample test for kinds of climatic factor. | ||||||||||
| model | HC−EK−01Series | HC−EK05− 05Series | HC-EK-10Series | ||||||||
| volume of the workroom(m³) | customized according to customers requirements. | ||||||||||
| Specifications | temperature range | -20°C -40°-60°C~+100°C | |||||||||
| humidity range | 20~98%R.H(+20°C~+80°C) | ||||||||||
| temperature deviation | ≤±2°C | ||||||||||
| humidity deviation | ±2.0%RH(>75%RH),±3±2.0%RH(>75%RH),±3.0%RH(≤75%RH)0%RH(≤75%RH) | ||||||||||
| temperature fluctuation | ≤±0.5°C | ||||||||||
| heating rate | ≥3-5°C/min(better than national standard ) | ||||||||||
| Cooling rate | ≥1-1.5°C/min(better than national standard ) | ||||||||||
| refrigeration compressor | Hermetically sealed compressor "Taikang” imported From French / Semi-hermetic compressor Gulun of German | ||||||||||
| refrigerant | environmental protection HFC-R404A/HFC-R23 | ||||||||||
| cooling mode | Air-Cooling or water cooling | ||||||||||
| Airflow mode | single cycle,stem extension,Stainless Steel centrifuge blade. | ||||||||||
| mode of refrigerant | cell refrigeration/double refrigeration | ||||||||||
| Water supply | built-in water tank | ||||||||||
| dehumidification | freeze | ||||||||||
| control system | Fuji of Japan's /a LCD touch screen of Japan's OYO /LCD touch screen of Korea (TEMI880) | ||||||||||
| Temperature Control | procedure&program | ||||||||||
| Security device | Multiple alarm device such as:electric leakage,water shortage,overheat,over pressure of compresor,overcurrent | ||||||||||
| Standard Configuration | internally heated hollow glass observation window | ||||||||||
| Power Supply | 380V±10%50Hz 3P+N+G | ||||||||||
| Standards Applied | GB2423.1-89 Basic environmental testing procedures for electrician electronic products(Test A Test method of low temperature) GB/T2423.3-93 Basic environmental testing procedures for electrician electronic products (Test method of muggy temperature ) GB/T2423.4-1993 Test Db Test method of alternate muggy temperature | ||||||||||
Demision Table:
| Volume | Inner size(D×W×H) | Workroom Outer(D×W×H) | Complete(D×W×H) | Door(D×W×H) | |||||||
| 8M3 | 2000×2000×2000 | 900×2300×2550 |
(3900~4550)×2300×2550 | 1000×2000* | |||||||
| 10M3 | 2500×2000×2000 | 3400×2300×2550 | (4500~5050)×2300×2550 | 1000×2000* | |||||||
| 12M3 | 2500×2500×2000 | 3400×2800×2550 | (4500~5050)×2800×2550 | 1000×2000* | |||||||
| 14M3 | 3200×2000×2200 | 4100×2300×2750 | (5100~5750)×2300×2750 | 1000×2000* | |||||||
| 16M3 | 3200×2000×2500 | 4100×2300×3050 | (5100~5750)×2300×3050 | 1000×2500* | |||||||
| 20M3 | 3600×2500×2200 | 4500×2800×2750 | (5500~6150)×2800×2750 | 2000×2200 | |||||||
| 22M3 | 3600×2500×2500 | 4500×2800×3050 | (5500~6150)×2800×3050 | 2000×2500 | |||||||
| 25M3 | 4000×2500×2500 | 4900×2800×3050 | (5900~6550)×2800×3050 | 2000×2500 | |||||||
| 26M3 | 4000×3000×2200 | 4900×3300×2750 | (5900~6550)×3300×2750 | 2500×2200 | |||||||
| 32M3 | 5200×2500×2500 | 6100×2800×3050 | (7100~7800)×2800×3050 | 2000×2500 | |||||||
| 34M3 | 5200×3000×2200 | 6100×3300×2550 | (7100~7800)×3300×2550 | 2500×2200 | |||||||
| 38M3 | 3600×3500×3000 | 4650×3800×3550 | (5650~6300)×3800×3550 | 2500×2500 | |||||||
| 44M3 | 4400×4000×2500 | 5450×4300×3050 | (6450~7100)×4300×3050 | 2500×2500 | |||||||
| 46M3 | 4400×3500×3000 | 5450×3800×3550 | (6450~7100)×3800×3550 | 2500×2500 | |||||||
| 48M3 | 4800×4000×2500 | 5850×4300×3050 | (6850~7500)×4300×3050 | 2500×2500 | |||||||
| 84M3 | 7000×4000×3000 | 8100×4300×3550 | 4000×3000 | ||||||||
| 300M3 | 10000×5000×6000 | 11100×5300×6550 | 4000×4000 | ||||||||
Packaging: Wooden Box
Delivery:Shipped in 4~6 weeks after payment
Why Bonad
We have specialized in lab and testing equipment for years.We are experienced and professional.We are proud of our products and service!
Excellent products performance
•Products Design and Development
Our tech team have more than 15 years of experience in lab equipment, which enable our products become reliable. A new products have to be tested for thousand times to ensure its environmental adaptation , easy application, stable operation
•Perfect Products Quality Control System
Pre-production quality control
Row materials is provided by quality suppliers and some of parts are imported from Germany, USA and Japan, which ensure the good quality at the source. Meanwhile, we will test the materials and parts before mass production.
Mid-production quality control
Our QC team will work through the whole production process.
Acceptance test
Each instruments must be carried out 100% quality examination before the shipment.
Best Service
The staff at Bonad is committed to providing you with most appropriate solution to save your time and money . We not only make products, but also sell products. Bonad owns its factories and provides with all kinds of OEM/ODM services. More than this, Bonad knows the market and customer requirements. We not only sell products, but also serve customers and solve problems so we have established long term cooperation with our customers. That’s why we stand behind our results. If you need any help, just remember we are here to listen and hel
