product description:
Battery short-circuit tester | ||
|
User Friendly LCD touch screen panel 17 segments adjustable backlight RS-485 communication port 9 programmable P.I.D temperature control segments EEPROM memory storage Build-in humidity sensor (±1%RH) |
|
Outer Structure |
Made of Cold Rolled Steel |
|
Chamber Structure |
Double layer steel chamber for anti-explosion Inside chamber: made of 1 mm thickness cold rolled SS304 with thensile strength > 500 Mpa Outside casing: made of 3 mm thickness annealed A3 steel with Tensile strength > 400 Mpa |
|
Working Temperature |
0℃ ~ +80℃ |
|
Temperature Accuracy |
±0.1℃ |
|
Temperature Fluctuation |
±0.5℃ |
|
Temperature Uniformity |
±2.0℃ |
|
Min. Temperature |
0℃ |
|
Heating Rate |
3℃/min |
|
Cooling Rate |
0.7~1℃/min |
|
Chamber Dimensions |
W600 X H750 X D500 MM |
|
Overall Dimensions |
W1800 X H1840 X D1030MM |
|
Crushing System & Voltage Measurement | ||
Features |
Panasonic AC Driving System Pulse Command Control High precision force sensor RS232 communication port Testing result can be saved as EXCEL format One brand new laptop with installed software are included for immediate use. |
|
Power supply |
208-240V, 3 phase, 50- 60Hz |
|
Max. Loading |
1 N~1300N |
|
Force Resolution |
1/10000 |
|
Force Accuracy |
≤0.5%F.S |
|
Force Magnification |
7 Segments Automatically |
|
Movement Resolution |
1/10000 |
|
Movement Accuracy |
≤0.5%F.S |
|
Speed Range |
0.01 ~ 5mm/s |
|
Effective Travel Distance |
150mm (without the clamp) |
|
Space for Crushing Test |
200mm W X 200mm L (without the clamp) |
|
Voltage Collecting Range |
0—20V |
|
Voltage Collecting Frequence |
100Hz |
|
Voltage Resolution Ratio |
1mV |
|
Compliance |
CE Certified All Electric pars are NRTL Certified and ready to pass UL/MET/ETL/CSA/TUV test at extra cost |
|
Warranty |
One year limited warranty with lifetime support |
|
Battery Overcharge Tester Battery Impact Tester
Battery Impact Tester Battery altitude test chamber Battery Needle Puncture Tester
1.Are your company a trading one or a factory ?
Factory + trade (integration),10 years focusing on test instruments field,3 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 26 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
