Mini Paint Film Coating Thickness Gauge meter film thickness meter equipment painting thickness tester
Overview-Mini Paint Film Coating Thickness Gauge meter film thickness meter equipment painting thickness tester
ED instrument is a portable,non-destructive,rapid and accurate measurement of coating thickness precision instruments.Widely used in anti-corrosion, electroplating,chemical, automotive,shipbuilding,aviation,light industry,suitable for laboratory,factory and outdoor field use.This product complies with GB/T4957-2003 standards.
The magnetic thickness gage,according to magnetic induction principle,to detect the magnetic metal substrate without damage. ( such as: iron , steel, and the hard magnetic alloy steel, etc.) On the thickness of the non -magnetic coating (such as: zinc , aluminum, chromium, copper , paint, Lang , rubber, paint, etc. ) .
According to the vortex theory,vortex thickness gauge detect the non-magnetic metal without damage.(such as:aluminum , copper, zinc , tin, etc. ) On thickness of the non-conductive coating ( such as paints, the anodic oxide film , ceramics, plastics, rubber, etc. ) .
Probe structure-Mini Paint Film Coating Thickness Gauge meter film thickness meter equipment painting thickness tester
All probes are installed in the casing, in order to ensure safe and stable probe positioning and the probe is touch with pressure probe moderately. V -groove end of the pin can ensure accurate on the convex.You must hold the tube on the probe when measuring, keeping the probe axis perpendicular to the test surface . Tip of the probe,which made of durable hard materials.
Parameter-Mini Paint Film Coating Thickness Gauge meter film thickness meter equipment painting thickness tester
| Measuring range | F type:0~3000μm |
| error | ±1μm or ±2~4% |
| The minimum radius of curvature | 5mm(convex);25mm(concave) |
| Minimum measuring area | φ20mm |
| Minimum substrate thickness | 0.5mm(F);50μm(N) |
| Display | 4 digi display,Optional backlit |
| Measuring unit | Um-mils optional |
| Calibration methods | standard,1point,2point |
| Power | 2AA batteries |
