Corrugated Carton Compression Tester + Packaging Box Compress Tester
Description
Carton Box Compression Test Machine Corrugated Box Compression Tester is used to test the compressive strength of cartons,containers and other packaging structure,which helps to get known of the compression strengthand impact-resistant capacity of product packaging in the transportation,stacking process.
It's adopts Load Sensor,resistance values directly displayed on the screen through the computer system.
Standard
Industrial Standard: GB/T4857.4 GB/T4857.16 ISO2872,ASTM D642
Manufacturing Standard: GB/T16491,TAPPI-T804,JIS-Z0212
Applicable Industry
Corrugated Carton Compression Tester is applicable to all factories and enterprise, technical supervision departments the commodity inspection authorities, research institutes and other department for testing and researching.
Technical Parameter
Model |
DZ-602 |
Max. load |
1T,2T,5T or customize |
Units |
kgf, Ibf, N, KN, kPa, MPa |
Resolution |
1/100,000 |
Accuracy |
0.5% |
Compression space |
100*100*100cm (or designated) |
Motor |
AC Servo Motor + Driver |
Test speed |
12~350mm/min |
Protector |
Leakage protection, overload auto-shutdown, displacement limit protection |
Structure |
computer system,motor servo/inverter,precision ball screw |
Volume |
153×121×180cm |
Power |
AC 220V, 5A |
Product Image
Carton Compression Tester Bursting Strength Tester Edge Ring Crush Tester Simulated Transport Vibration Tester
ZONHOW Though 10 years of continuous development, our company has established the main products line of Universal strength testing machines for tension, compression, flexure, and shear etc. Environmental testing chambers and Cell phone, computer testing machines. Package and paper print test equipment and so on! Our equipment is used in over 80 countries worldwide and supported by a network of offices and approved agencies. Our products are used in all industries and educational sectors and we have an enviable reputation for innovation, quality product and excellent customer support.
We have professional packing teams and shipping forwarder to pack and deliver your products!
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.
1.Are your company a trading one or a factory ?
Factory + trade (integration),12 years focusing on test instruments field,5 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 120 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
