Construction
Terminal and contact support are manufactured from a single piece of metal. The
contacts are resistance-welded to the terminal for increased mechanical strength.
Rating
These switches are suitable for motor loads and power applications up to
15A 250VAC or 10A 400VAC
Metal or insulated lever
UL, CSA and NF-VDE (EN 61058-1) approved
APEM Reset switch 631H/2
ELECTRICAL SPECIFICATIONS
Max. current/voltage ratings : see tables below
Peak current : 30A max. during 1/2 sine, 250VAC
Initial contact resistance : 10 mΩ max. at 1A 2VDC
Insulation resistance : 1.000 MΩ min. at 500VDC
Dielectric strength :
2.000 Vrms 50 Hz min. between terminals
2.500 Vrms 50 Hz min. between terminals and frame
• Electrical life : 10.000 cycles at full load
We provide Only New and original parts with high quality.You could rest assure to choose our products to be your favorite! We will never let you donw.
2-3days for shipment.
