Golden laser | Fanuc robot arm 3D fiber laser cutting system for shaped tube cutting

The robot laser cutting machine is applied to all kinds of uneven metal pipe and sheet metal cutting, suitable for the automotive industry, mold manufacturing, kitchen utensils, metal products etc.

Applicable Industry

For automotive sheet metal coverings and chassis parts and other batches of small quantities of production, such as maintenance market, trucks, buses, construction machinery, modified cars and so on.

With the flexible production of laser, instead of open stamping, suitable for personalized production, but also shorten the product development cycle, rapid response to the market.

With the robot laser cutting, instead of hand-held plasma cutting, greatly simplifies the process, but also has been plagued by the manufacturer's plasma workers in the management of the problem.

Applicable material

Specially for carbon steel, stainless steel, galvanized steel, alloy, titanium, aluminum and other metal materials.

Main Features

It perfectly integrated with the world famous ABB, Stabuli, Fanuc robot arm and fiber cutting technology that represents the most advanced level of laser cutting, so it can realize automated production.

6-axis linkage makes the working area larger and reach long stretch distance with long loading ability, so it can perform 3D track cutting within the working space.

Due to the compact structure and slim robot wrist, it can realize high performance operation even if with limited floor restriction.

The process speed and position can be adjusted to achieve the best manufacturing precision and good production rate.

Low noise and long routine maintenance intervals, so the machine service time is longer.

The robot arm can be controlled by the manual handle.

By changing the program and machine hardware, the robot arm can acheve the function of laser cutting or laser wedling.

Technical Parameter

Model number: ABB IRB 2400, Staubli TX160L, Fanuc M20iA

Laser source: imported fiber laser resonator

Laser source power: 700W/1200w/1500w/2000w

Stretch diameter: ≤2m

Position accuracy: +0.08mm/m

Max. position speed: 30m/min

Laser cutting head；Raytools 3D cutting head

Cutting speed: depend on material, laser source power

Machine loading weight: 500kg

Electric power supply: AC380V 50/60Hz
