2017 Aisry Hot selling 50 HZ fixed frequency electromagnetic vibration testing machine for Circuit boards
Application:
50 HZ fixed frequency electromagnetic vibration testing machine can be used to identify whether the product is put up for environmental vibration for electronic, electrical, optical , steam locomotives, toys, packaging and other industries ...... research, development, quality control, and manufacturing.
Technical parameters:
| Table Size |
35 * 35 * 10 cm (L × W × H) |
| Test Load |
50KG |
| Frequency Range | 50HZ |
| Amplitude | 0 ~ 5MM |
| Acceleration | 20g |
| The vibration direction |
vertical |
| vibration waveforms | sine wave |
| The power supply voltage (V) |
220 V |
| Maximum current |
3A |
| Power | 2 KW |
Mechanical structure and material:
1. The load plate adopts imported advanced SUS31NNI hafnium aluminum alloy sheet, for loads up to 40KG.
2. Test tops, paint production, rubbing, nice.
3. The inside of the machine with variable speed vibration controlled rail, study hard and durable.
4. The control system uses a control program can be realistically simulated field test.
Protection device:
1. The timing of when to automatically cut off the power supply unit
2. overload, automatically cut off power supply unit
3. With safety warning light device
Attachment:
quality assurance book
instructions.
Operation environment:
Ambient temperature range performance guarantees: + 5 ℃ ~ + 55 ℃
(Except for the lowest up to temperature, the maximum heat load capacity and cooling time)
Product details:
