Particulate Filtration Efficiency Tester PFE ASTM F2100
Application
It is to test the filtering efficiency of particulate protective masks and medical masks and to determine the resistance of ordinary fabrics and medical protective masks to the constant flow of airflow.
Standards
GB/T 32610-2016,GB 2626-2006,GB19082-2009,GB 19083-2010
GB 24539-2009 ,YY 0469-2011 ,YYT0969-2013
Specifications
Item |
specification |
Test range |
0-99.999% |
Flowmeter range |
(10-100)L/min, |
Sampling frequency |
1-9999/min |
Particle concentration |
(0.001-200)mg/m3 |
Counting median diameter |
Salt particles(0.075±0.02)μm,Oil particles(0.185±0.02)μm |
Features
l Using a cold aerosol generator to produce continuous and stable aerosol particles, convenient for filling the solution.
l Measurement of aerosol concentration using a high-precision PM2.5 sensor.
Anti-leakage design of whole particles to protect the safety of laboratory personnel.
2 sets of Aerosol generator:Salty aerosol generator and oily aerosol generator.
l Equipped with aerosol particle neutralization device.
l The pneumatic clamp is equipped with a protection device, which is safe and convenient to use.
l Configure temperature and humidity sensor, real-time display of ambient temperature and humidity(Temperature and humidity requirements:25℃±5℃,30%RH±10%RH).
Equipped with glass rotor flowmeter, vacuum pump, laser dust particle counter.
l Control system: The computer controls the test process, automatically collects data, and configures a special computer and test software.
The computer automatically tests the gas concentration and calculates the filtration efficiency. It can save, output, query and print the test data.
Factory View:
Certifications:
Our Customer:
Our Service:
1. One year guarantee and all lifetime techinical support
2. USA, Australia Aisa Local agent for service
3. Speedy reply, 12hrs response to customer questions
4. Software free update
5. Minor maintenance ---parts ship within 24 hrs
6. Major maintenance---Technical will be sent within 15 days
Our Lab:
Our Team:
Why Choose Us Contact Us?
1.We are the largest packaging test equipment manufacturer in China.
2. We are the only reference materail certificated supplier in the world.
3. Most of the provincial, municipal FDA using our testers in China.
