Medical Equipment Digital 6 (Six) Channel Portable ECG Machine Electrocardiograph
Negotiable
/ Unit
1 Unit(Min.Order)
- 500 Unit / Units per Month
- Zhengzhou
- T/T Other
- 5 days
You May Like
- Saikang Table Lamp Battery Operated
- Surgery 2 Vaporizers Anesthesia machine, Different types Anesthesia machine, Portable Anesthesia
- Hongyang Medical ICU Ventilator with Air compressor ZXH-600D 12.1 inch Folding Screen
- Hongyang Medical ICU Ventilator with Air compressor ZXH-600 12.1 inch Touch Screen
- Hongyang Medical Portable Anesthesia machine GSM-II with Ventilator
- Hongyang Medical Portable Anesthesia machine GSM-II Veterinary Use
Product Details
Brand Name: | BENEMED | Place of Origin: | China | Model Number: | BM-ECG6A |
Type: | First-Aid Devices |
Product Description
Features:
3/4(3-6)/6 channel printout format
5.1 inch 320×240 LCD to display ECG waveform, setting menu and operating status
Rhythm lead with R-R interval histogram and trend graph
Automatic measurement and interpretation of standard ECG parameters
Seamless communication with HIS firmat of JPG, PDF, ect
Optional ECG viewer software for futhuer data management
Paper size: 112mm×20m, roll type
Specification:
Lead | Standard 12 lead | Rhythm Lead | Standard 12 lead |
Input Ciruit | Isolated: Protection against pace making and defibrillation | Operation Mode | AUTO/MAN |
Input Impeedance | ≥50MΩ | Frequency Response | 0.05-150Hz(-3dB) |
Input Circuit Current | ≤50nA | Paper Speed | 25,50mm/s±3% |
Calibrating Voltage | 1mV±3% | Recording Paper | Roll paper/Z fold 112mm×30m/112mm×75m |
Skin Voltage Tolerance | ±300mV | Sampling Rate | 1.25ms |
Sensitivity | 5, 10, 20mm/mV | A/D Converter | 12bit |
Filter | AC:50Hz(-20dB); EMG:35-45Hz(-3dB) | LCD | 320Z×240graph LCD |
CMRR | ≥100dB | Power Requirements | AC: 220V, 50 Hz/110V,60Hz DC: Built in rechargeable battery Supprting 50 exams after complete charging |
Time Constant | ≥ 3.2s (0, +20%) | ||
Noise Level | ≤15μVp-p | External Signal | 10mm/mV±5%; Single ended≥100KΩ |
Baseline Control | Automatic position | ECG Output | 0.5V/mV±5%; Single ended≤100Ω |
Printer | Thermal array printer | Package | 640×400×530mm;240×310×370mm(1 set) |
Safety Level | Class I, Type CF | Weight | 4 Kgs |
