Hotsale Cheap Digital Hospital Electrocardiograph 12 Channel ECG Machine

Name: Hotsale Cheap Digital Hospital Electrocardiograph 12 Channel ECG Machine
Brand: BENEMED
SKU: 162943451
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

BENEMED

Place of Origin:

China

Model Number:

BM-ECG12A

BENEMED (HK) Industry Co. Limted

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhengzhou

Delivery Detail:

5 days

Brand Name BENEMED

Place of Origin China

Model Number BM-ECG12A

Type First-Aid Devices

Features:

Specification:

leat	Standard 12 lead	Memory	16 exams in memory for recall and duplication
Input Ciruit	Isolated: Protection against pace making and defibrillation	A/D Converter	12 bit
Input Impeedance	≥50MΩ	Recording Paper	Roll paper/Z fold 210mm×30m/210mm×20m
Input Circuit Current	≤50nA	Operation Mode	AUTO/MAN
Calibrating Voltage	1mV±3%	Rhythm Lead	Standard 12 lead
Skin Voltage Tolerance	±300nV	External Signal	10mm/mV/mV±5%; Single ended≥100KΩ
Sensitivity	5,10,20,40mm/mV	ECG Output	0.5V/mV±5%; Single ended≥100Ω
Filter	AC:50Hz(-20dB); EMG:30-45Hz(-3dB)	Safety Level	Class I, Type CF
Paper Speed	6.25, 12.5, 25, 50mm/s ±3%	Power Requirements	AC: 220V, 50 Hz/110V,60Hz DC: Built in rechargeable battery Supprting 50 exams after complete charging
Time Constant	≥ 3.2s (0, +20%)
Noise Level	≤15μVp-p
Frequency Response	0.05-150Hz(-3dB)
Sampling Rate	1.25ms	Package	50×41×23cm for 1 set
Baseline Control	Automatic position	Weight	5.5 Kgs
PC Connection	USB interface	Printer	Thermal array printer
