CHY-H1210 Compact 1200 degree Muffle Tube Furnace for multi using laboratory Muffle Furnace muffle furnace manufacturer
1.100*100*100mm chamber dimension
2.high quality ceramic fiber chamber
3.PID Programmable controller
4.Muffle Furnace/Tube Furnace multi-function using
5.Made by Henan Chengyi
Muffle Furnace APPLICATION
1.laboratory heat thermal processing cement, building materials industry etc
2.Pharmaceutical medicines inspection, preteatment of medical sample
3.Analytical Chemistry Industry: water analysis and environmental analysis
4.Analysis of coal quality,determine moisture, ash, volatile matter, ash melting point analysis, gray component analysis, and elemental analysis
PRODUCT PARAMETERS
Product Name |
1200 Degree Muffle Tube Furnace |
Model |
H1210 |
Furnace Door |
side open type |
Display Model |
Highlight LED display |
Maximum Temperature |
1150℃ |
Working Temperature |
≤1100℃ |
Heating rate |
≤20℃/min Suggest:10℃/min |
Heating zones |
Single heating zone |
Hearth dimensions |
100mm×100mm×100mm |
Hearth volume |
1L |
Tube Size |
O.D60*270mm |
Sealing method |
Vacuum sealing flange |
Vacuum degree |
10-3Pa with Turbo pump system |
Control mode |
Intelligent PID auto control |
Temperature Accuracy |
±1℃ |
Temperature curve |
30 segments programmable |
Over heat alarm |
Have |
Overcurrent protection |
Have |
Thermocouple Failure Protection |
Have |
Temperature measure element |
K-type thermocouple |
Heating Element |
Fe-Cr-Al Alloy doped by Mo |
Hearth Material |
high purity alumina fiber |
After-sales service |
12 month warranty, durable maintaince and repair support |
Power Supply |
220V 50HZ |
Rated power |
0.75kw |
Overall dimensions |
400×400×450 (mm ) |
Packing |
3-ply wooden case |
Accessories |
plate,protective glove,crucible hook,crucible tongs,quartz tube,vacuum flange,user manual. |
Our compact 1200c muffle furnace is electrically heated with coil heating elements supported on ceramic tubes generally provided on both side wall and back wall.
Founded in 2013, CHENGYI is a manufacturer of lab equipment. We not only can supply standard lab equipment, but also we do customized as request. We sincerely welcome worldwide friend come to visit us!
