Equipment description:
In order to meet the requirements of various CVD processes, we have integrated a number of temperature control instruments into the intelligent control system. You can complete all the parameter Settings by simply clicking the touch screen.While satisfying the gradient control of different temperature zones, multiple temperature zones can be set as the same temperature point, which can be used as extended single temperature zone.It continues the classic design of open tube furnace, beautiful and practical!
|
|||||||
|
1. 15 temperature curves can be stored in advance to avoid the trouble caused by repeated Settings of different experimental processes; 2. The experimental process is more intuitive and the operation is more convenient; 3. Wireless control module can be selected to realize remote control; 4. It has the functions of over temperature alarm, broken couple prompt, leakage protection and so on. |
|||||||
The temperature precision |
+/- 1 ℃ |
|||||||
Heating element |
|
|
||||||
Vacuum degree: ≤10Pa (mechanical pump) |
||||||||
| Experimental principle of CVD |
|
The float flowmeter is used to control the gas velocity, which is integrated with the equipment for easy control. |
||||||
The net weight |
60KG |
|||||||
Equipment precautions |
1. When the furnace temperature of the equipment is ≥300℃, do not open the furnace to avoid damage; 2. When the equipment is in use, the pressure inside the furnace shall not exceed 0.125mpa (absolute pressure) to prevent damage caused by excessive pressure; 3. When used under high vacuum (10 to the minus 3 Pa), the operating temperature of the equipment shall not exceed 800℃. |
|||||||
Service support |
1 year warranty with lifetime support (warranty excludes consumable parts such as furnace tubes and o-rings) |
|||||||
