Refrigeration Solder Type Hand Valve, Flare Type Hand Valve, Brass Valve, HVAC/R Valve

Model KM hand valve is a manually operated diaphragm stop valve for one-way flow control.

·Model KM hand valve is mounted on the liquid, air suction and hot air piping in the refrigeration, cold storage and air conditioner.

·Two types of connection are available for Model KM hand valve, that is, threaded connection (SAE) with threading size 1/4 SAE to 3/4 SAE and welded connection both ODF, structure hand valves have connection size 1/4” to 7/8”.

·All Model KM hand valves are equipped with mounting hole for the installation on the instrument panel.

Features:

There are 2 pieces of stainless steel diaphragm to prevent the hand valve from leakage during the whole service life of the hand valve;

The elastic sealing is used on the valve port so that the hand valve could be shut off by small torque;

The special valve bonnet design is sued to prevent the hand valve from water or dust penetration;

The hand valve is easy to be operated for full open or half open just by turning the valve stem for one and half turn.
